Danfoss Metasys N2 Design Guide

Model Enclosure size Rating Bussmann P/N Spare
Bussmann P/N
Estimated fuse power loss [W]
[V] (UL) [A] 600 V 690 V
P355 F8–F9 700 630 170M4016 176F8335 13 10
P400 F8–F9 700 630 170M4016 176F8335 17 13
P500 F8–F9 700 630 170M4016 176F8335 22 16
P560 F8–F9 700 630 170M4016 176F8335 24 18
P630 F10–F11 700 900 170M6013 176F8592 26 20
P710 F10–F11 700 900 170M6013 176F8592 35 27
P800 F10–F11 700 900 170M6013 176F8592 44 33
P900 F12–F13 700 1500 170M6018 176F9181 26 20
P1M0 F12–F13 700 1500 170M6018 176F9181 37 28
P1M2 F12–F13 700 1500 170M6018 176F9181 47 36
Table 10.25 Mains Fuses, 525–690 V
Model Bussmann PN Rating Siba
P450 170M8611 1100 A, 1000 V 20 781 32.1000
P500 170M8611 1100 A, 1000 V 20 781 32.1000
P560 170M6467 1400 A, 700 V 20 681 32.1400
P630 170M6467 1400 A, 700 V 20 681 32.1400
P710 170M8611 1100 A, 1000 V 20 781 32.1000
P800 170M6467 1400 A, 700 V 20 681 32.1400
Table 10.26 Inverter Module DC Link Fuses, 380–480 V
Model Bussmann PN Rating Siba
P630 170M8611 1100 A, 1000 V 20 781 32.1000
P710 170M8611 1100 A, 1000 V 20 781 32.1000
P800 170M8611 1100 A, 1000 V 20 781 32.1000
P900 170M8611 1100 A, 1000 V 20 781 32.1000
P1M0 170M8611 1100 A, 1000 V 20 781 32.1000
P1M2 170M8611 1100 A, 1000 V 20 781 32.1000
Table 10.27 Inverter Module DC Link Fuses, 525–690 V
The 170M fuses from Bussmann shown use the -/80 visual indicator. -TN/80 Type T, -/110, or TN/110 Type T indicator fuses
of the same size and amperage can be substituted for external use. To meet UL requirements, use any minimum 480 V UL
listed fuse with associated current rating.
Enclosure Models Type Default breaker settings
Trip level [A] Time [s]
F3 380–480 V, Model: P450
525–690 V, Model: P630–P710
Merlin Gerin
NPJF36120U31AABSCYP
1200 0.5
F3 380–480 V, Model: P500–P630
525–690 V, Model: P800
Merlin Gerin
NRJF36200U31AABSCYP
2000 0.5
F4 380–480 V, Model: P710
525–690 V, Model: P900–P1M2
Merlin Gerin
NRJF36200U31AABSCYP
2000 0.5
F4 380–480 V, Model: P800 Merlin Gerin
NRJF36250U31AABSCYP
2500 0.5
Table 10.28 Circuit Breakers, F3–F4
Electrical Installation Con... Design Guide
MG16C302 Danfoss A/S © 11/2017 All rights reserved. 181
10 10
