Danfoss Metasys N2 Design Guide

VLT
®
HVAC Drive FC 102
P710 P800 P900
Normal overload NO NO NO
(Normal overload=110% current during 60 s)
Typical shaft output at 550 V [kW] 560 670 750
Typical shaft output at 575 V [hp] 750 950 1050
Typical shaft output at 690 V [kW] 710 800 900
Enclosure size F10/F11 F10/F11 F10/F11
Output current (3-phase)
Continuous (at 550 V) [A] 763 889 988
Intermittent (60 s overload) (at 550 V) [A] 839 978 1087
Continuous (at 575/690 V) [A] 730 850 945
Intermittent (60 s overload) (at 575/690 V) [A] 803 935 1040
Continuous kVA (at 550 V) [kVA] 727 847 941
Continuous kVA (at 575 V) [kVA] 727 847 941
Continuous kVA (at 690 V) [kVA] 872 1016 1129
Maximum input current
Continuous (at 550 V) [A] 735 857 952
Continuous (at 575 V) [A] 704 819 911
Continuous (at 690 V) [A] 704 819 911
Maximum number and size of cables per phase
- Motor [mm
2
(AWG)]
8x150 (8x300 mcm) 8x150 (8x300 mcm) 8x150 (8x300
mcm)
- Mains [mm
2
(AWG)]
6x120 (4x900 mcm) 6x120 (4x900 mcm) 6x120 (4x900
mcm)
- Brake [mm
2
(AWG)]
4x185 (4x350 mcm) 4x185 (4x350 mcm) 4x185 (4x350
mcm)
Maximum external mains fuses [A]
1)
900 900 900
Estimated power loss at 600 V [W]
2), 3)
9500 10872 12316
Estimated power loss at 690 V [W]
2), 3)
9863 11304 12798
Maximum added losses for circuit breaker or disconnect and contactor
[W], (F11 only)
427 532 615
Maximum panel options losses [W] 400 400 400
Eciency
3)
0.98 0.98 0.98
Output frequency [Hz] 0–500 0–500 0–500
Control card overtemperature trip [°C (°F)]
85 (185) 85 (185) 85 (185)
Table 7.11 Electrical Data for Enclosures F10/F11, Mains Supply 6x525–690 V AC
1) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
2) Typical power loss is at normal conditions and expected to be within
± 15% (tolerance relates to variety in voltage and cable conditions). These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to
drives.danfoss.com/knowledge-center/energy-
eciency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for
slots A and B each add only 4 W.
3) Measured using 5 m (16.5 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 10.12 Eciency. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
Specications
VLT
®
HVAC Drive FC 102
58 Danfoss A/S © 11/2017 All rights reserved. MG16C302
77

Danfoss Metasys N2 Specifications
