Item Fastener Wrench size Torque
D250 Electric control mounting bolt 5 mm internal hex 13 N•m [10 lbf•ft]
E085 Displacement limiter screw 4 mm internal hex NA
E090 Displacement limiter sealnut 13 mm 23 N•m [17 lbf•ft]
H130 Front cover bolt 8 mm internal hex
28/32 cc - 50 N•m [37 lbf•ft]
38/45 cc - 64 N•m [47 lbf•ft]
K300 Rear cover/aux pad mounting bolt 8 mm internal hex 111 N•m [82 lbf•ft]
MP1 plug size and torque
Item O-ring plug Wrench size Torque
G010/G035 Charge pressure gauge 6 mm or 1/4 inch
internal hex
40 N•m [29.5 Ft-lbs] for 9/16
35.3 N•m [26 Ft-lbs] for M14
G030/G040 Filtration inlet/outlet 6 mm or 1/4 inch
internal hex
40 N•m [29.5 Ft-lbs] for 9/16
35.3 N•m [26 Ft-lbs] for M14
G020/G025 Servo gauge (28/32) 6 mm or 3/16 inch
internal hex
25 N•m [18.4 Ft-lbs] for 7/16
25 N•m [18.4 Ft-lbs] for M12
G020/G025 Servo gauge (38/45) 6 mm or 1/4 inch
internal hex
40 N•m [29.5 Ft-lbs] for 9/16
35.3 N•m [26 Ft-lbs] for M14
G060/065 Case drain 12 mm or 9/16 in
internal hex
48 N•m [36 Ft-lbs]
G070/075 System gauge (28/32) 19 mm or 11/16
inch wrench
38 N•m [28 Ft-lbs] for 9/16
24 N•m [17.7 lbf-ft] for M14
System gauge (38/45) 24 mm or 7/8 inch
wrench
81 N•m [59.7 Ft-lbs] for 3/4
67 N•m [49.4 lbf-ft] for M18
M100/N100 High pressure relief 5/16 inch internal
hex
81.0 N•m [59.7 Ft-lbs]
V100 Charge pressure relief 1 inch 78.6 N•m [58 Ft-lbs]
Service Manual
MP1
Fastener size and torque chart
©
Danfoss | April 2019 AX00000244en-000201 | 65
