✭ = factory setting. ( ) = parameter window text. [ ] = value for use in communication via serial communication port
Programming
Description of choice:
The table below shows when the motor is running
and is coasting when Digital input [0], Serial
communication [1], Logic and [2] or Logic or [3] has
been selected.
NB!:
Please note that terminal 27 and bit 03 of the
control word are active in the case of logic '0'.
Digital input [0] Serial communication [1]
Serial Serial
Kl. 27 com. Function Kl. 27 com. Function
0 0 Coasting 0 0 Coasting
0 1 Coasting 0 1 Motor run.
1 0 Motor run. 1 0 Coasting
1 1 Motor run. 1 1 Motor run.
Logic and [2] Logic or [3]
Serial Serial
Kl. 27 com. Function Kl. 27 com. Function
0 0 Coasting 0 0 Coasting
0 1 Motor run. 0 1 Coasting
1 0 Motor run. 1 0 Coasting
1 1 Motor run. 1 1 Motor run.
Digital input [0] Serial communication [1]
Term. Serial Term.Seriel
19/27 com. Function 19/27 com. Function
0 0 DC-brake 0 0 DC-brake
0 1 DC-brake 0 1 Motor run.
1 0 Motor run. 1 0 DC-brake
1 1 Motor run. 1 1 Motor run.
Logic and [2] Logic or [3]
Term. Serial Term.Serial
19/27 com. Function 19/27 com. Function
0 0 DC-brake 0 0 DC-brake
0 1 Motor run. 0 1 DC-brake
1 0 Motor run. 1 0 DC-brake
1 1 Motor run. 1 1 Motor run.
505 Start (START)
Value:
Digital input (DIGITAL INPUT) [0]
Serial communication (SERIAL PORT) [1]
Logic and(LOGIC AND) [2]
★ Logic or (LOGIC OR) [3]
Function:
See the functional description under parameter 503
Coasting.
Description of choice:
The table below shows when the motor has stopped
and gives the situations in which the VLT frequency
converter has a start command when Digital input [0],
Serial communication [1], Logic and [2] or Logic or [3]
has been selected.
Digital input [0] Serial communication [1]
Serial Serial
Kl. 18 com. Function Kl. 18 com. Function
0 0 Stop 0 0 Stop
0 1 Stop 0 1 Start
1 0 Start 1 0 Stop
1 1 Start 1 1 Start
Logic and [2] Logic or [3]
Serial Serial
Kl. 18 com. Function Kl. 18 com. Function
0 0 Stop 0 0 Stop
0 1 Stop 0 1 Start
1 0 Stop 1 0 Start
1 1 Start 1 1 Start
504 DC brake (DC BRAKE)
Value:
Digital input (DIGITAL INPUT) [0]
Serial communication (SERIAL PORT) [1]
Logic and (LOGIC AND) [2]
★ Logic or (LOGIC OR) [3]
Function:
See functional description under parameter 503
Coasting.
Description of choice:
The table below shows when the motor is running
and is DC-braking when Digital input [0], Serial
communication [1], Logic and [2] or Logic or [3] has
been selected.
NB!:
Please note that DC braking inverse [3] via
terminal 19, terminal 27 and bit 03 of the
control word is active in the case of logic '0'.
