Danfoss VLT 6000 HVAC

VLT
®
6000 HVAC
MG.60.B1.02 - VLT is a registered Danfoss trademark
134
✭ = factory setting. ( ) = parameter window text. [ ] = value for use in communication via serial communication port
507 Selection of Setup (SELECTING OF SETUP)
508 Selection of preset reference
(SELECTING OF SPEED)
Value:
Digital input (DIGITAL INPUT) [0]
Serial communication (SERIAL PORT) [1]
Logic and (LOGIC AND) [2]
★ Logic or (LOGIC OR) [3]
Function:
See the functional description under parameter 503
Coasting.
Description of choice:
The table below shows the Setup (parameter 002
Active Setup) that has been selected via
Digital input [0], Serial communication [1],
Logic and [2] or Logic or [3].
The table also shows the preset reference
(parameters 211-214 Preset reference) that has been
selected via Digital input [0], Serial communication [1],
Logic and [2] or Logic or [3].
Digital input [0]
Bus Bus Setup/Preset Setup/Preset Setup nr.
msb lsb msb lsb Preset ref. no.
00 0 0 1
00 0 1 2
00 1 0 3
00 1 1 4
01 0 0 1
01 0 1 2
01 1 0 3
01 1 1 4
10 0 0 1
10 0 1 2
10 1 0 3
10 1 1 4
11 0 0 1
11 0 1 2
11 1 0 3
11 1 1 4
506 Reversering (REVERSING)
Value:
★ Digital input (DIGITAL INPUT) [0]
Serial communication (SERIAL PORT) [1]
Logic and (LOGIC AND) [2]
Logic or (LOGIC OR) [3]
Function:
See the functional description under parameter 503
Coasting.
Description of choice:
The table below shows when the motor is running
clockwise and anti-clockwise when Digital input [0],
Serial communication [1], Logic and [2] or Logic or [3]
has been selected.
Digital input [0] Serial communication [1]
Serial Serial
Kl. 19 com. Function Kl. 19 com. Function
0 0 Clockwise 0 0 Clockwise
0 1 Clockwise 0 1 Clockwise
1 0 Anti-clock. 1 0 Clockwise
1 1 Anti-clock. 1 1 Anti-clock.
Logic and [2] Logic or [3]
Serial Serial
Kl. 19 com. Function Kl. 19 com. Function
0 0 Clockwise 0 0 Clockwise
0 1 Clockwise 0 1 Anti-clock.
1 0 Clockwise 1 0 Anti-clock.
1 1 Anti-clock. 1 1 Anti-clock.
