Danfoss VLT AHF 005 Design Guide

130BF589.10
0.0
35 (1.4) 87 (3.4)
122 (4.8) 174 (6.8)
0.0
135 (5.3)
437 (17.2)
0.0
533 (21.0)
44 (1.7)
244 (9.6)
1
2
1 Mains terminals 2 Ground bar
Illustration 8.38 Terminal Dimensions for F3–F4 Options Cabinet with Circuit Breaker/Molded Case Switch (380–480/500 V Models:
P450; 525–690 V Models: P630–P710), Side View
Exterior and Terminal Dimen...
VLT
®
HVAC Drive FC 102
102 Danfoss A/S © 11/2017 All rights reserved. MG16C302
88
