7.2 Electrical Data, 525–690 V
VLT
®
HVAC Drive FC 102
P450 P500 P560 P630
Normal overload NO NO NO NO
(Normal overload=110% current during 60 s)
Typical shaft output at 550 V [kW] 355 400 450 500
Typical shaft output at 575 V [hp] 450 500 600 650
Typical shaft output at 690 V [kW] 450 500 560 630
Enclosure size E1/E2 E1/E2 E1/E2 E1/E2
Output current (3-phase)
Continuous (at 550 V) [A] 470 523 596 630
Intermittent (60 s overload) (at 550 V) [A] 517 575 656 693
Continuous (at 575/690 V) [A] 450 500 570 630
Intermittent (60 s overload) (at 575/690 V) [A] 495 550 627 693
Continuous kVA (at 550 V) [kVA] 448 498 568 600
Continuous kVA (at 575 V) [kVA] 448 498 568 627
Continuous kVA (at 690 V) [kVA] 538 598 681 753
Maximum input current
Continuous (at 550 V) [A] 453 504 574 607
Continuous (at 575 V) [A] 434 482 549 607
Continuous (at 690 V) 434 482 549 607
Maximum number and size of cables per phase
- Mains, motor, and load share [mm
2
(AWG)]
4x240 (4x500
mcm)
4x240 (4x500
mcm)
4x240 (4x500
mcm)
4x240 (4x500
mcm)
- Brake [mm
2
(AWG)]
2x185 (2x350
mcm)
2x185 (2x350
mcm)
2x185 (2x350
mcm)
2x185 (2x350
mcm)
Maximum external mains fuses [A]
1)
700 700 900 900
Estimated power loss at 600 V [W]
2), 3)
5323 6010 7395 8209
Estimated power loss at 690 V [W]
2), 3)
5529 6239 7653 8495
Eciency
3)
0.98 0.98 0.98 0.98
Output frequency [Hz] 0–500 0–500 0–500 0–500
Control card overtemperature trip [°C (°F)]
85 (185) 85 (185) 85 (185) 85 (185)
Table 7.7 Electrical Data for Enclosures E1/E2, Mains Supply 3x525–690 V AC
1) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
2) Typical power loss is at normal conditions and expected to be within
± 15% (tolerance relates to variety in voltage and cable conditions). These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-
eciency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for
slots A and B each add only 4 W.
3) Measured using 5 m (16.5 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 10.12 Eciency. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
