8.5
F3 Exterior and T
erminal Dimensions
8.5.1
F3
Exterior
Dimensions
130BF376.10
2280
(89.7)
2204
(86.8)
2000 (78.8)
606
(23.9)
578
(22.8)
578
(22.8)
776
(30.6)
Illustration
8.33
Front,
Side,
and
Door
Clearanc
e
Dimensions
for
F3
Exterior and T
erminal Dimen...
Design Guide
MG16C302
Danfoss A/S © 11/2017 All rights reserved.
97
8
8
98
100
