EtherNet/IP MCA 121
Ethernet is the future standard for communication at the
factory oor. The VLT
®
EtherNet/IP MCA 121 option is
based on the newest technology available for industrial
use and handles even the most demanding requirements.
EtherNet/IP™ extends standard commercial Ethernet to the
Common Industrial Protocol (CIP™) – the same upper-layer
protocol and object model found in DeviceNet.
MCA 121
oers advanced features such as:
•
Built-in, high-performance switch enabling line-
topology, which eliminates the need for external
switches.
•
DLR Ring (from October 2015).
•
Advanced switch and diagnosis functions.
•
Built-in web server.
•
E-mail client for service notication.
•
Unicast and Multicast communication.
6.1.7
VLT
®
Modbus TCP MCA 122
The MCA 122 option connects to Modbus TCP-based
networks. It handles connection intervals down to 5 ms in
both directions, positioning it among the fastest
performing Modbus TCP devices in the market. For master
redundancy, it features hot swapping between 2 masters.
Other features include:
•
Built-in web-server for remote diagnosis and
reading out basic drive parameters.
•
Email notication that can be congured to send
an email message to 1 or more recipients when
certain alarms or warnings occur, or when they
are cleared.
•
Dual master PLC connection for redundancy.
6.1.8
VLT
®
BACnet/IP MCA 125
The VLT
®
BACnet/IP MCA 125 option allows quick and easy
integration of the drive into building management systems
(BMS) using the BACnet/IP protocol or by running BACnet
on Ethernet. It can read and share data points and transfer
actual and requested values to and from the systems.
The MCA 125 option has 2 Ethernet connectors, enabling
daisy-chain conguration with no need for external
switches. The embedded 3-port managed switch of the
VLT
®
BACnet/IP MCA 125 option comprises 2 external and
1 internal Ethernet port. This switch allows the use of a
line structure for the Ethernet cabling. This option makes it
possible to control multiple high-eciency permanent
magnet motors in parallel and monitor points required in
typical HVAC applications. Besides standard functionality,
the MCA 125 option features:
•
COV (change of value).
•
Read/write property multiple.
•
Alarm/warning notications
•
Ability to change BACnet object names for user-
friendliness.
•
BACnet Loop object.
•
Segmented data transfer.
•
Trending, based on time or event.
6.2 Functional Extensions
This section describes the functional extension options that
are available with the VLT
®
HVAC Drive series. For ordering
numbers, refer to chapter 13.2 Ordering Numbers for
Options/Kits.
6.2.1
VLT
®
General Purpose I/O Module
MCB 101
The MCB 101 option oers an extended number of control
inputs and outputs:
•
3 digital inputs 0–24 V: Logic 0 < 5 V; Logic 1 >
10 V.
•
2 analog inputs 0–10 V: Resolution 10 bits plus
sign.
•
2 digital outputs NPN/PNP push-pull.
•
1 analog output 0/4–20 mA.
•
Spring-loaded connection.
6.2.2
VLT
®
Relay Card MCB 105
The MCB 105 option extends relay functions with 3 more
relay outputs.
•
Protects control cable connection.
•
Spring-loaded control wire connection.
Maximum switch rate (rated load/minimum load)
6 minutes
-1
/20 s
-1
.
Maximum terminal load
AC-1 resistive load: 240 V AC, 2 A.
6.2.3
VLT
®
Analog I/O Option MCB 109
The VLT
®
Analog I/O Option MCB 109 is easily tted in the
drive for upgrading to advanced performance and control
using the additional inputs/outputs. This option also
upgrades the drive with a battery back-up supply for the
Options and Accessories Ove... Design Guide
MG16C302 Danfoss A/S © 11/2017 All rights reserved. 43
