Danfoss VLT AHF 005 Design Guide

210 (8.3)
0.0
66 (2.6)
181 (7.1)
296 (11.7) 431 (17.0) 546 (21.5) 661 (26.0) 796 (31.3) 911 (35.8)
1026 (40.4)
246 (9.7)
294 (11.6) 330 (13.0) 575 (22.6) 611 (24.0) 659 (25.9) 695 (27.4) 939 (37.0) 975 (38.4)
1023 (40.3) 1059 (41.7)
144 (5.7) 219 (8.6)
512 (20.2) 587 (23.1) 880 (34.7) 955 (37.6)
3
130BF363.10
1
2
1 Brake terminals 3 Ground bar
2 Motor terminals – –
Illustration 8.53 Terminal Dimensions for F2/F4 Inverter Cabinet, Front View
Exterior and Terminal Dimen... Design Guide
MG16C302 Danfoss A/S © 11/2017 All rights reserved. 117
8 8
