8.7.2 F8 Terminal Dimensions
Power cables are heavy and hard to bend. To ensure easy installation of the cables, consider the optimum placement of the
drive. Each terminal allows up to 4 cables with cable lugs or a standard box lug. Ground is connected to a relevant
termination point in the drive.
2
3
130BF645.10
R2/L12
R1/L11
91-1
91
S2/L22
S1/L21
92-1 T2/L32 93-1
92
T1/L31 93
U/T1 96 V/T2 97 W/T3 98
0.0
58 (2.3)
74 (2.9)
100 (3.9)
139 (5.5)
173 (6.8)
189 (7.4)
199 (7.8)
288 (11.3)
304 (12.0)
407 (16.0)
464 (18.2)
522 (20.6)
524 (20.6)
630 (24.8)
637 (25.1)
1 Mains terminals 3 Ground bar
2 Motor terminals – –
Illustration 8.58 Terminal Dimensions for F8–F9 Rectier/Inverter Cabinet, Front View
Exterior and Terminal Dimen...
VLT
®
HVAC Drive FC 102
122 Danfoss A/S © 11/2017 All rights reserved. MG16C302
