EN 61000-4-5 (IEC 61000-4-5): Surge transients: Simulation of transients brought about by lightning strikes near
installations.
•
EN 61000-4-6 (IEC 61000-4-6): RF common mode: Simulation of the eect from radio-transmission equipment
joined by connection cables.
Basic standard Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
ESD
IEC
61000-4-2
Radiated
electro-magnetic eld
IEC 61000-4-3
RF common
mode voltage
IEC 61000-4-6
Acceptance criterion B B B A A
Line 4 kV CM
2 kV/2 Ω DM
4 kV/12 Ω CM
– – 10 V
RMS
Motor 4 kV CM
4 kV/2 Ω
1)
– – 10 V
RMS
Brake 4 kV CM
4 kV/2 Ω
1)
– – 10 V
RMS
Load sharing 4 kV CM
4 kV/2 Ω
1)
– – 10 V
RMS
Control wires 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
Standard bus 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
Relay wires 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
Application/eldbus options 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
LCP cable 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
External 24 V DC 2 V CM
0.5 kV/2 Ω DM
1 kV/12 Ω CM
– – 10 V
RMS
Enclosure – – 8 kV AD
6 kV CD
10 V/m –
Table 10.42 EMC Immunity Form, Voltage Range: 380–480/500 V, 525–600 V, 525–690 V
1) Injection on cable shield.
AD: air discharge; CD: contact discharge; CM: common mode; DM: dierential mode.
10.15.4 EMC Compatibility
NOTICE
OPERATOR RESPONSIBILITY
According to the EN 61800–3 standard for variable-speed drive systems, the operator is responsible for ensuring EMC
compliance. Manufacturers can oer solutions for operation conforming to the standard. Operators are responsible for
applying these solutions, and for paying the associated costs.
There are 2 options for ensuring electromagnetic compatibility.
•
Eliminate or minimize interference at the source of emitted interference.
•
Increase the immunity to interference in devices aected by its reception.
RFI
lters
The goal is to obtain systems that operate stably without radio frequency interference between components. To achieve a
high level of immunity, use drives with high-quality RFI lters.
NOTICE
RADIO INTERFERENCE
In a residential environment, this product can cause radio interference, in which case supplementary mitigation
measures may be required.
PELV and galvanic isolation compliance
All E1h–E4h drives control and relay terminals comply with PELV (excluding grounded Delta leg above 400 V).
Galvanic (ensured) isolation is obtained by fullling requirements for higher isolation and by providing the relevant
creepage/clearance distances. These requirements are described in the EN 61800–5–1 standard.
Electrical Installation Con...
