Harmonic order (h) Class 1 (V
h
%) Class 2 (V
h
%) Class 3 (V
h
%)
5 3 6 8
7 3 5 7
11 3 3.5 5
13 3 3 4.5
17 2 2 4
17˂h≤49 2.27 x (17/h) – 0.27 2.27 x (17/h) – 0.27 4.5 x (17/h) – 0.5
Table 10.47 Compatibility Levels for Harmonics
Class 1 Class 2 Class 3
THDv 5% 8% 10%
Table 10.48 Compatibility Levels for the Total Harmonic Voltage Distortion THDv
10.17.4 Harmonic Compliance
Danfoss drives comply with the following standards:
•
IEC61000-2-4
•
IEC61000-3-4
•
G5/4
10.17.5 Harmonic Mitigation
In cases where extra harmonic suppression is required, Danfoss oers the following mitigation equipment:
•
VLT
®
12-pulse drives
•
VLT
®
Low harmonic drives
•
VLT
®
Advanced harmonic lters
•
VLT
®
Advanced active lters
Selecting the right solution depends on several factors:
•
The grid (background distortion, mains unbalance, resonance, and type of supply (transformer/generator).
•
Application (load prole, number of loads, and load size).
•
Local/national requirements/regulations (such as IEEE 519, IEC, and G5/4).
•
Total cost of ownership (initial cost, eciency, and maintenance).
10.17.6 Harmonic Calculation
Use the free Danfoss MCT 31 calculation software to determine the degree of voltage pollution on the grid and needed
precaution. The VLT
®
Harmonic Calculation MCT 31 is available at www.danfoss.com.
Electrical Installation Con... Design Guide
MG16C302 Danfoss A/S © 11/2017 All rights reserved. 199
10 10
