13.2.3 Ordering Numbers for Kits
Type Description Ordering number
Miscellaneous hardware
USB in door, E1 and F1–F13 USB extension cord kit to allow access to the drive controls via laptop
computer without opening the drive.
E1–E2 – 130B1156
F1–F13 – 176F1784
Top entry - motor cables, F1/F3 Allows for the installation of motor cables through the top of the
motor side cabinet. Must be used with the common motor terminals
kit. Only for enclosures F1/F3.
400 mm (15.7 in) cabinet –
176F1838
600 mm (23.6 in) cabinet –
176F1839
Top entry - motor cables, F2/F4 Allows for the installation of motor cables through the top of the
motor side cabinet. Must be used with the common motor terminals
kit. Only for enclosures F2/F4.
400 mm (15.7 in) cabinet –
176F1840
600 mm (23.6 in) cabinet –
176F1841
Top entry - motor cables,
F8–F13
Allows for the installation of motor cables through the top of the
motor side cabinet. Must be used with the common motor terminals
kit. Only for enclosures F8–F13.
Contact factory
Top entry - mains cables, F1–F2 Allows for the installation of mains cables through the top of the
mains side cabinet. The kit must be ordered with the common motor
terminals kit. Only for enclosures F1–F2.
400 mm (15.7 in) cabinet –
176F1832
600 mm (23.6 in) cabinet –
176F1833
Top entry - mains cables, F3–F4
with disconnect
Allows for the installation of mains cables through the top of the
mains side cabinet. The kit must be ordered with the common motor
terminals kit. Only for enclosures F3–F4 with disconnect.
400 mm (15.7 in) cabinet –
176F1834
600 mm (23.6 in) cabinet –
176F1835
Top entry - mains cables, F3–F4 Allows for the installation of mains cables through the top of the
mains side cabinet. The kit must be ordered with the common motor
terminals kit. Only for enclosures F3–F4.
400 mm (15.7 in) cabinet –
176F1836
600 mm (23.6 in) cabinet –
176F1837
Top entry - mains cables,
F8–F13
Allows for the installation of mains cables through the top of the
mains side cabinet. The kit must be ordered with the common motor
terminals kit. Only for enclosures F8–F13.
Contact factory
Top entry - eldbus cables, E2 Allows for the installation of eldbus cables through the top of the
drive. The kit is IP20/Chassis when installed, but a dierent mating
connector can be used to increase the protection rating. Only for
enclosure E2.
176F1742
Common motor terminals,
F1–F4
Provides the busbars and hardware required to connect the motor
terminals from the paralleled inverters to a single terminal (per phase)
to accommodate the installation of the motor-side top entry kit. This
kit is equivalent to the common motor terminal option of a drive.
This kit is not required to install the motor-side top entry kit if the
common motor terminal option was specied when the drive was
ordered.
Also recommended to connect the output of a drive to an output
lter or output contactor. The common motor terminals eliminate the
need for equal cable lengths from each inverter to the common point
of the output lter (or motor).
400 mm (15.7 in) cabinet –
176F1845
600 mm (23.6 in) cabinet –
176F1846
NEMA 3R enclosure, E2 Designed to be used with the IP00/IP20/Chassis drives to achieve an
ingress protection rating of NEMA 3R or NEMA 4. These enclosures are
intended for outdoor use to provide a degree of protection against
inclement weather. Only for enclosures E2.
Welded enclosure – 176F0298
Rittal enclosure – 176F1852
Pedestal, E1–E2 The pedestal kit is a 400 mm (15.8 in) high pedestal that allows the
drive to be oor mounted. The front of the pedestal has openings for
input air to cool the power components. Only for enclosures E1–E2.
176F6739
Input options plate, E1–E2 Allows fuses, disconnect/fuses, RFI, RFI/fuses, and RFI/disconnect/fuses
to be added. Only for enclosures E1–E2. Contact factory
