Recommended max. fuse
Power
(hp [kW])
Max. prefuse
size [A]
Buss-
mann
JFHR2
Buss-
mann
RK1
Buss-
mann
J
Buss-
mann
T
Buss-
mann
CC
Buss-
mann
CC
Buss-
mann
CC
SIBA
RK1
Littel
fuse
RK1
Ferraz-
Shawmut
CC
Ferraz-
Shawmut
RK1
Ferraz-
Shawmut
J
10 [7.5] 60
FWH-6
0
KTS-
R60 JKS-60 JJS-60
501400
6-063
KLS-
R60 - A6K-60R HSJ60
15 [11] 80
FWH-8
0
KTS-
R80 JKS-80 JJS-80
202822
0-100
KLS-
R80 - A6K-80R HSJ80
30 [22] 150
FWH-1
50
KTS-
R150
JKS-15
0
JJS-15
0
202822
0-160
KLS-
R150 - A6K-150R HSJ150
50 [37] 200
FWH-2
00
KTS-
R200
JKS-20
0
JJS-20
0
202822
0-200
KLS-20
0 A6K-200R HSJ200
Table 10.17 1 x 380–500 V
KTS fuses from Bussmann may substitute KTN for 240 V adjustable frequency drives
FWH fuses from Bussmann may substitute FWX for 240 V adjustable frequency drives
JJS fuses from Bussmann may substitute JJN for 240 V adjustable frequency drives
KLSR fuses from LITTLE FUSES may substitute KLNR fuses for 240 V adjustable frequency drives
A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V adjustable frequency drives
Recommended max. fuse
Power (hp
[kW])
Bussmann
Type RK1
1)
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann Bussmann
Type CC
0.34–0.5
[0.25–0.37]
KTN-R-05 JKS-05 JJN-05 FNQ-R-5 KTK-R-5 LP-CC-5
0.75–1.5
[0.55–1.1]
KTN-R-10 JKS-10 JJN-10 FNQ-R-10 KTK-R-10 LP-CC-10
2 [1.5] KTN-R-15 JKS-15 JJN-15 FNQ-R-15 KTK-R-15 LP-CC-15
3 [2.2] KTN-R-20 JKS-20 JJN-20 FNQ-R-20 KTK-R-20 LP-CC-20
4 [3.0] KTN-R-25 JKS-25 JJN-25 FNQ-R-25 KTK-R-25 LP-CC-25
5 [3.7] KTN-R-30 JKS-30 JJN-30 FNQ-R-30 KTK-R-30 LP-CC-30
7.5–10
[5.5–7.5]
KTN-R-50 KS-50 JJN-50 - - -
15 [11] KTN-R-60 JKS-60 JJN-60 - - -
20 [15] KTN-R-80 JKS-80 JJN-80 - - -
25–30
[18.5–22]
KTN-R-125 JKS-125 JJN-125 - - -
40 [30] KTN-R-150 JKS-150 JJN-150 - - -
50 [37] KTN-R-200 JKS-200 JJN-200 - - -
60 [45] KTN-R-250 JKS-250 JJN-250 - - -
Table 10.18 3 x 200–240 V, Frame Sizes A, B and C
Specifications
VLT
®
AQUA Drive
Instruction Manual
10-22 MG20M922 - VLT
®
is a registered Danfoss trademark
10
10
