Recommended max. fuse
Power (hp
[kW])
SIBA
Type RK1
Littel fuse
Type RK1
Ferraz-
Shawmut
Type CC
Ferraz-
Shawmut
Type RK1
3)
0.34–0.5
[0.25–0.37]
5017906-005 KLN-R-05 ATM-R-05 A2K-05-R
0.75–1.5
[0.55–1.1]
5017906-010 KLN-R-10 ATM-R-10 A2K-10-R
2 [1.5] 5017906-016 KLN-R-15 ATM-R-15 A2K-15-R
3 [2.2] 5017906-020 KLN-R-20 ATM-R-20 A2K-20-R
4 [3.0] 5017906-025 KLN-R-25 ATM-R-25 A2K-25-R
5 [3.7] 5012406-032 KLN-R-30 ATM-R-30 A2K-30-R
7.5–10
[5.5–7.5]
5014006-050 KLN-R-50 - A2K-50-R
15 [11] 5014006-063 KLN-R-60 - A2K-60-R
20 [15] 5014006-080 KLN-R-80 - A2K-80-R
25–30
[18.5–22]
2028220-125 KLN-R-125 - A2K-125-R
40 [30] 2028220-150 KLN-R-150 - A2K-150-R
50 [37] 2028220-200 KLN-R-200 - A2K-200-R
60 [45] 2028220-250 KLN-R-250 - A2K-250-R
Table 10.19 3 x 200–240 V, Frame Sizes A, B and C
Recommended max. fuse
Power (hp
[kW])
Bussmann
Type JFHR2
2)
Littel fuse
JFHR2
Ferraz-
Shawmut
JFHR2
4)
Ferraz-
Shawmut
J
0.34–0.5
[0.25–0.37]
FWX-5 - - HSJ-6
0.75–1.5
[0.55–1.1]
FWX-10 - - HSJ-10
2 [1.5] FWX-15 - - HSJ-15
3 [2.2] FWX-20 - - HSJ-20
4 [3.0] FWX-25 - - HSJ-25
5 [3.7] FWX-30 - - HSJ-30
7.5–10
[5.5–7.5]
FWX-50 - - HSJ-50
15 [11] FWX-60 - - HSJ-60
20 [15] FWX-80 - - HSJ-80
25–30
[18.5–22]
FWX-125 - - HSJ-125
40 [30] FWX-150 L25S-150 A25X-150 HSJ-150
50 [37] FWX-200 L25S-200 A25X-200 HSJ-200
60 [45] FWX-250 L25S-250 A25X-250 HSJ-250
Table 10.20 3 x 200–240 V, Frame Sizes A, B and C
1) KTS fuses from Bussmann may substitute for KTN for 240 V adjustable frequency drives.
2) FWH fuses from Bussmann may substitute for FWX for 240 V adjustable frequency drives.
3) A6KR fuses from FERRAZ SHAWMUT may substitute for A2KR for 240 V adjustable frequency drives.
4) A50X fuses from FERRAZ SHAWMUT may substitute for A25X for 240 V adjustable frequency drives.
