Danfoss VLT AQUA Drive FC 202 Instruction Manual

Recommended max. fuse
Power
(hp [kW])
Bussmann
Type RK1
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
- KTS-R-6 JKS-6 JJS-6 FNQ-R-6 KTK-R-6 LP-CC-6
1.5–3
[1.1–2.2]
KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
4 [3] KTS-R-15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
5 [4] KTS-R-20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
7.5 [5.5] KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
10 [7.5] KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
15 [11] KTS-R-40 JKS-40 JJS-40 - - -
20 [15] KTS-R-50 JKS-50 JJS-50 - - -
30 [22] KTS-R-60 JKS-60 JJS-60 - - -
40 [30] KTS-R-80 JKS-80 JJS-80 - - -
50 [37] KTS-R-100 JKS-100 JJS-100 - - -
60 [45] KTS-R-125 JKS-125 JJS-125 - - -
75 [55] KTS-R-150 JKS-150 JJS-150 - - -
100 [75] KTS-R-200 JKS-200 JJS-200 - - -
125 [90] KTS-R-250 JKS-250 JJS-250 - - -
Table 10.21 3 x 380–480 V, Frame Sizes A, B and C
Recommended max. fuse
Power (hp [kW]) SIBA
Type RK1
Littel fuse
Type RK1
Ferraz-
Shawmut
Type CC
Ferraz-
Shawmut
Type RK1
- 5017906-006 KLS-R-6 ATM-R-6 A6K-6-R
1.5–3 [1.1–2.2] 5017906-010 KLS-R-10 ATM-R-10 A6K-10-R
4 [3] 5017906-016 KLS-R-15 ATM-R-15 A6K-15-R
5 [4] 5017906-020 KLS-R-20 ATM-R-20 A6K-20-R
7.5 [5.5] 5017906-025 KLS-R-25 ATM-R-25 A6K-25-R
10 [7.5] 5012406-032 KLS-R-30 ATM-R-30 A6K-30-R
15 [11] 5014006-040 KLS-R-40 - A6K-40-R
20 [15] 5014006-050 KLS-R-50 - A6K-50-R
30 [22] 5014006-063 KLS-R-60 - A6K-60-R
40 [30] 2028220-100 KLS-R-80 - A6K-80-R
50 [37] 2028220-125 KLS-R-100 - A6K-100-R
60 [45] 2028220-125 KLS-R-125 - A6K-125-R
75 [55] 2028220-160 KLS-R-150 - A6K-150-R
100 [75] 2028220-200 KLS-R-200 - A6K-200-R
125 [90] 2028220-250 KLS-R-250 - A6K-250-R
Table 10.22 3 x 380–480 V, Frame Sizes A, B and C
Specifications
VLT
®
AQUA Drive
Instruction Manual
10-24 MG20M922 - VLT
®
