Recommended max. fuse
Power (hp [kW]) Bussmann
JFHR2
Ferraz-Shawmut
J
Ferraz-Shawmut
JFHR2
1)
Littel fuse
JFHR2
- FWH-6 HSJ-6 - -
1.5–3 [1.1–2.2] FWH-10 HSJ-10 - -
4 [3] FWH-15 HSJ-15 - -
5 [4] FWH-20 HSJ-20 - -
7.5 [5.5] FWH-25 HSJ-25 - -
10 [7.5] FWH-30 HSJ-30 - -
15 [11] FWH-40 HSJ-40 - -
20 [15] FWH-50 HSJ-50 - -
30 [22] FWH-60 HSJ-60 - -
40 [30] FWH-80 HSJ-80 - -
50 [37] FWH-100 HSJ-100 - -
60 [45] FWH-125 HSJ-125 - -
75 [55] FWH-150 HSJ-150 - -
100 [75] FWH-200 HSJ-200 A50-P-225 L50-S-225
125 [90] FWH-250 HSJ-250 A50-P-250 L50-S-250
Table 10.23 3 x 380–480 V, Frame Sizes A, B and C
1) Ferraz-Shawmut A50QS fuses may substitute for A50P fuses.
Recommended max. fuse
Power (hp [kW]) Bussmann
Type RK1
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
1–1.5 [0.75–1.1] KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5
2–3 [1.5–2.2] KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
4 [3] KTS-R15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
4 KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
7.5 [5.5] KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
10 [7.5] KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
15–20 [11–15] KTS-R-35 JKS-35 JJS-35 - - -
25 [18] KTS-R-45 JKS-45 JJS-45 - - -
30 [22] KTS-R-50 JKS-50 JJS-50 - - -
40 [30] KTS-R-60 JKS-60 JJS-60 - - -
50 [37] KTS-R-80 JKS-80 JJS-80 - - -
60 [45] KTS-R-100 JKS-100 JJS-100 - - -
75 [55] KTS-R-125 JKS-125 JJS-125 - - -
100 [75] KTS-R-150 JKS-150 JJS-150 - - -
125 [90] KTS-R-175 JKS-175 JJS-175 - - -
Table 10.24 3 x 525–600 V, Frame Sizes A, B and C
Specifications
VLT
®
AQUA Drive
Instruction Manual
MG20M922 - VLT
®
is a registered Danfoss trademark 10-25
