Danfoss VLT AQUA Drive FC 202 Instruction Manual

Recommended max. fuse
Power (hp
[kW])
SIBA
Type RK1
Littel fuse
Type RK1
Ferraz-
Shawmut
Type RK1
Ferraz-
Shawmut
J
1–1.5 [0.75–
1.1]
5017906-005 KLS-R-005 A6K-5-R HSJ-6
2–3 [1.5–2.2] 5017906-010 KLS-R-010 A6K-10-R HSJ-10
4 [3] 5017906-016 KLS-R-015 A6K-15-R HSJ-15
5 [4] 5017906-020 KLS-R-020 A6K-20-R HSJ-20
7.5 [5.5] 5017906-025 KLS-R-025 A6K-25-R HSJ-25
10 [7.5] 5017906-030 KLS-R-030 A6K-30-R HSJ-30
15–20 [11–15] 5014006-040 KLS-R-035 A6K-35-R HSJ-35
25 [18] 5014006-050 KLS-R-045 A6K-45-R HSJ-45
30 [22] 5014006-050 KLS-R-050 A6K-50-R HSJ-50
40 [30] 5014006-063 KLS-R-060 A6K-60-R HSJ-60
50 [37] 5014006-080 KLS-R-075 A6K-80-R HSJ-80
60 [45] 5014006-100 KLS-R-100 A6K-100-R HSJ-100
75 [55] 2028220-125 KLS-R-125 A6K-125-R HSJ-125
100 [75] 2028220-150 KLS-R-150 A6K-150-R HSJ-150
125 [90] 2028220-200 KLS-R-175 A6K-175-R HSJ-175
Table 10.25 3 x 525–600 V, Frame Sizes A, B and C
1) 170M fuses shown from Bussmann use the -/80 visual indicator. –TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted.
Recommended max. fuse
Power (hp
[kW])
Max.
prefuse
[A]
Bussmann
E52273
RK1/JDDZ
Bussmann
E4273
J/JDDZ
Bussmann
E4273
T/JDDZ
SIBA
E180276
RK1/JDDZ
LittelFuse
E81895
RK1/JDDZ
Ferraz-
Shawmut
E163267/E2137
RK1/JDDZ
Ferraz-
Shawmut
E2137
J/HSJ
15–20 [11–
15]
30 KTS-R-30 JKS-30 JKJS-30 5017906-030 KLS-R-030 A6K-30-R HST-30
30 [22] 45 KTS-R-45 JKS-45 JJS-45 5014006-050 KLS-R-045 A6K-45-R HST-45
40 [30] 60 KTS-R-60 JKS-60 JJS-60 5014006-063 KLS-R-060 A6K-60-R HST-60
50 [37] 80 KTS-R-80 JKS-80 JJS-80 5014006-080 KLS-R-075 A6K-80-R HST-80
60 [45] 90 KTS-R-90 JKS-90 JJS-90 5014006-100 KLS-R-090 A6K-90-R HST-90
75 [55] 100 KTS-R-100 JKS-100 JJS-100 5014006-100 KLS-R-100 A6K-100-R HST-100
100 [75] 125 KTS-R-125 JKS-125 JJS-125 2028220-125 KLS-150 A6K-125-R HST-125
125 [90] 150 KTS-R-150 JKS-150 JJS-150 2028220-150 KLS-175 A6K-150-R HST-150
* UL-compliance 525–600 V only
Table 10.26 3 x 525–690 V*, Frame Sizes B and C
Specifications
VLT
®
AQUA Drive
Instruction Manual
10-26 MG20M922 - VLT
®
is a registered Danfoss trademark
10
10
