Danfoss VLT AQUA Drive FC 202 Installation Manual

Mains supply 3x380–480 VAC
P315 P355 P400 P450
High/normal load* HO NO HO NO HO NO HO NO
Typical shaft output at 400 V
[kW]
250 315 315 355 355 400 400 450
Typical shaft output at 460 V
[HP]
350 450 450 500 500 600 550 600
Typical shaft output at 480 V
[kW]
315 355 355 400 400 500 500 530
Enclosure protection rating
IP21
E9 E9 E9 E9
Enclosure protection rating
IP54
E9 E9 E9 E9
Output current
130BA230.10
Continuous (at 400 V) [A] 480 600 600 658 658 745 695 800
Intermittent (60 s overload) (at
400 V) [A]
720 660 900 724 987 820 1043 880
Continuous (at 460/480 V) [A] 443 540 540 590 590 678 678 730
Intermittent (60 s overload) (at
460/480 V) [A]
665 594 810 649 885 746 1017 803
Continuous KVA (at 400 V)
[KVA]
333 416 416 456 456 516 482 554
Continuous KVA (at 460 V)
[KVA]
353 430 430 470 470 540 540 582
Continuous KVA (at 480 V)
[KVA]
384 468 468 511 511 587 587 632
Maximum input current
130BA229.10
Continuous (at 400 V) [A] 472 590 590 647 647 733 684 787
Continuous (at 460/480 V) [A] 436 531 531 580 580 667 667 718
Maximum cable size, mains,
motor, and load share [mm
2
(AWG
2)
)]
4x240
(4x500 mcm)
4x240
(4x500 mcm)
4x240
(4x500 mcm)
4x240
(4x500 mcm)
Maximum cable size, brake
[mm
2
(AWG
2)
)
2x185
(2x350 mcm)
2x185
(2x350 mcm)
2x185
(2x350 mcm)
2x185
(2x350 mcm)
Maximum external mains fuses
[A]
1)
700 900 900 900
Total LHD loss 400 V AC [kW] 11587 14051 14140 15320 15286 17180 16036 18447
Total back channel loss 400 V
AC [kW]
9011 11301 10563 11648 11650 13396 12348 14570
Total lter loss 400 V AC [kW] 6528 7346 7346 7788 7788 8503 8060 8974
Total LHD loss 460 V AC [kW] 10962 12936 13124 14083 13998 15852 15847 16962
Total back channel loss 460 V
AC [kW]
8432 10277 9636 10522 10466 12184 12186 13214
Total lter loss 460 V AC [kW] 6316 7066 7006 7359 7326 8033 8033 8435
Weight, enclosure protection
rating IP21, IP54 [kg]
596 623 646 646
Eciency
4)
0.96
Acoustic noise 72 dBa
Output frequency 0–600 Hz
Heat sink overtemperature trip 105 °C
Power card ambient trip 85 °C
* High overload = 160% current for 60 s, normal overload = 110% current for 60 s.
Table 8.2 E-frame Ratings
