Danfoss vlt aqua Design Guide

Description Pos.: Possible choice
Coating PCB 20
X. No coated PCB
C: Coated PCB
Line power option 21
D: Loadsharing
X: No line power disconnect switch
8: Line Power Disconnect + Loadsharing
Cable entries 22
X: Standard cable entries
O: European metric thread in cable entries
23 Reserved
Software release 24-27 Current software version
Software language 28
A options 29-30
AX: No options
A0: MCA 101 Profibus DP V1
A4: MCA 104 DeviceNet
AN: MCA 121 Ethernet IP
B options 31-32
BX: No option
BK: MCB 101 General purpose I/O option
BP: MCB 105 Relay option
BO:MCB 109 Analog I/O option
BY: MCO 101 Extended Cascade Control
C
0
options
33-34 CX: No options
C
1
options
35
X: No options
5: MCO 102 Advanced Cascade Control
C option software 36-37 XX: Standard software
D options 38-39
DX: No option
D0: DC backup
The various options are described further on in this Design Guide.
Table 4.2: Type code description.
VLT
®
AQUA Drive Design Guide 4 How to Order
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 4-3
4

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
