Danfoss vlt aqua Design Guide

4.1.3 Type Code String High Power
Description Pos.: Possible choice
Product group & VLT Series 1-6 FC 202
Power rating 7-10 0.34–1600 hp [0.25–1200 kW]
Number of phases 11 Three phases (T)
AC line voltage 11-12
S2: 220–240 V AC single phase
S4: 380–480 V AC single phase
T 2: 200–240 V AC
T 4: 380–480 V AC
T 6: 525–600 V AC
T 7: 525–690 V AC
Enclosure 13-15
E20: IP20
E21: IP 21/NEMA Type 1
E55: IP 55/NEMA Type 12
E2M: IP21/NEMA Type 1 w/ line power shield
E5M: IP 55/NEMA Type 12 w/ line power shield
E66: IP66
F21: IP21 kit without backplate
G21: IP21 kit with backplate
P20: IP20/chassis with backplate
P21: IP21/NEMA Type 1 w/ backplate
P55: IP55/NEMA Type 12 w/ backplate
RFI filter 16-17
HX: No RFI filter
H1: RFI filter class A1/B
H2: RFI filter class A2
H3: RFI filter class A1/B (reduced cable length)
H4: RFI filter class A2/A1
Brake 18
X: No brake chopper included
B: Brake chopper included
T: Safe Stop
U: Safe + brake
Display 19
G: Graphical Local Control Panel (GLCP)
N: Numeric Local Control Panel (NLCP)
X: No Local Control Panel
Coating PCB 20
X. No coated PCB
C: Coated PCB
Line power option 21
D: Loadsharing
X: No line power disconnect switch
8: Line Power Disconnect + Loadsharing
Cable entries 22
X: Standard cable entries
O: European metric thread in cable entries
23 Reserved
Software release 24-27 Current software version
Software language 28
Table 4.3: Type code description.
4 How to Order VLT
®
AQUA Drive Design Guide
4-4 MG.20.N5.22 - VLT
®
is a registered Danfoss trademark
4
