Danfoss vlt aqua Design Guide

4.2.2 Ordering Numbers: Harmonic Filters
Harmonic filters are used to reduce line harmonics.
• AHF 010: 10% current distortion
• AHF 005: 5% current distortion
380–415 V, 50Hz
I
AHF,N
Typical Motor Used [kW] Danfoss ordering number
Adjustable frequency drive
size
AHF 005 AHF 010
10 A 1.1–4 175G6600 175G6622 P1K1, P4K0
19 A 5.5–7.5 175G6601 175G6623 P5K5 - P7K5
26 A 11 175G6602 175G6624 P11K
35 A 15–18.5 175G6603 175G6625 P15K - P18K
43 A 22 175G6604 175G6626 P22K
72 A 30 - 37 175G6605 175G6627 P30K - P37K
101A 45 - 55 175G6606 175G6628 P45K - P55K
144 A 75 175G6607 175G6629 P75K
180 A 90 175G6608 175G6630 P90K
217 A 110 175G6609 175G6631 P110
289 A 132 - 160 175G6610 175G6632 P132 - P160
324 A 175G6611 175G6633
370 A 200 175G6688 175G6691 P200
506 A 250
175G6609
+ 175G6610
175G6631
+ 175G6632
P250
578 A 315 2x 175G6610 2x 175G6632 P315
648 A 400 2x175G6611 2x175G6633 P400
380–415 V, 60 Hz
I
AHF,N
Typical Motor Used [HP] Danfoss ordering number
Adjustable frequency drive
size
AHF 005 AHF 010
19 A 10 - 15 130B2460 130B2472 P5K5 - P7K5
26 A 20 130B2461 130B2473 P11K
35 A 25 - 30 130B2462 130B2474 P15K, P18K
43 A 40 130B2463 130B2475 P22K
72 A 50 - 60 130B2464 130B2476 P30K - P37K
101A 75 130B2465 130B2477 P45K - P55K
144 A 100 - 125 130B2466 130B2478 P75K
180 A 150 130B2467 130B2479 P90K
217 A 200 130B2468 130B2480 P110
289 A 250 130B2469 130B2481 P132
324 A 300 130B2470 130B2482 P160
370 A 350 130B2471 130B2483 P200
506 A 450 130B2468
+ 130B2469
130B2480
+ 130B2481
P250
578 A 500 2x 130B2469 2x 130B2481 P315
648 A 500 2x130B2470 2x130B2482 P355
VLT
®
AQUA Drive Design Guide 4 How to Order
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 4-9
4

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
