Danfoss vlt aqua Design Guide

440–480 V, 60 Hz
I
AHF,N
Typical Motor Used [HP] Danfoss ordering number
Adjustable frequency drive
size
AHF 005 AHF 010
19 A 10 - 15 175G6612 175G6634 P11K
26 A 20 175G6613 175G6635 P15K
35 A 25 - 30 175G6614 175G6636 P18K, P22K
43 A 40 175G6615 175G6637 P30K
72 A 50 - 60 175G6616 175G6638 P37K - P45K
101A 75 175G6617 175G6639 P55K
144 A 100 - 125 175G6618 175G6640 P75K
180 A 150 175G6619 175G6641 P90
217 A 200 175G6620 175G6642 P110
289 A 250 175G6621 175G6643 P132 - P160
324 A 300 175G6689 175G6692
370 A 350 175G6690 175G6693 P200
434 A 350 2x175G6620 2x175G6642 P250
578 A 500 2x 175G6621 2x 175G6643 P315 - P355
659 A 550-600 175G6690 + 175G6621 175G6693 + 175G6643 P400
Matching the adjustable frequency drive and filter is pre-calculated based on 400 V/480 V, a typical motor load (4-pole) and 110% torque.
500–525 V, 50 Hz
I
AHF,N
Typical Motor Used [kW] Danfoss ordering number
Adjustable frequency drive
size
AHF 005 AHF 010
10 A 0.75–5.5 175G6644 175G6656 PK75 - P5K5
19 A 7.5–11 175G6645 175G6657 P7K5 - P11K
26 A 15 18.5 175G6646 175G6658 P15K - P18K
35 A 22 175G6647 175G6659 P22K
43 A 30 175G6648 175G6660 P30K
72 A 37 -45 175G6649 175G6661 P37K - P45K
101 A 55 - 75 175G6650 175G6662 P55K - P75K
144 A 90 - 110 175G6651 175G6663 P90K - P110
180 A 132 175G6652 175G6664 P132
217 A 160 175G6653 175G6665 P160
289 A 200 175G6654 175G6666 P200
324 A 250 175G6655 175G6667 P250
370 A 315 2x175G6653 2x175G6665 P315 - P400
578 A 400 2X 175G6654 2X 175G6666 P500 - P560
4 How to Order VLT
®
AQUA Drive Design Guide
4-10 MG.20.N5.22 - VLT
®
is a registered Danfoss trademark
4

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
