Danfoss vlt aqua Design Guide

690 V, 50 Hz
I
AHF,N
Typical Motor Used [kW] Danfoss ordering number
Adjustable frequency drive
size
AHF 005 AHF 010
43 37 - 45 130B2328 130B2293
72 55 - 75 130B2330 130B2295 P37K - P45K
101 90 130B2331 130B2296 P55K - P75K
144 A 110 - 132 130B2333 130B2298 P90K - P110
180 A 160 130B2334 130B2299 P132
217 A 200 130B2335 130B2300 P160
289 A 250 130B2331+2333 130B2301 P200
324 A 315 130B2333+2334 130B2302 P250
370 A 400 130B2334+2335 130B2304 P315
VLT
®
AQUA Drive Design Guide 4 How to Order
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 4-11
4

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
