Danfoss vlt aqua Design Guide

4.2.5 Ordering Numbers: du/dt Filters, 380–480 VAC
Line power supply 3x380 to 3x480 V
Adjustable frequency drive size
Minimum switching fre-
quency
Maximum output fre-
quency
Part No. IP20 Part No. IP00
Rated filter current at
50 Hz
380–440 V 441–480 V
15 hp [11 kW] 15 hp [11 kW] 4 kHz 60 Hz 130B2396 130B2385 24 A
20 hp [15 kW] 20 hp [15 kW] 4 kHz 60 Hz 130B2397 130B2386 45 A
25 hp [18.5 kW] 25 hp [18.5 kW] 4 kHz 60 Hz 130B2397 130B2386 45 A
30 hp [22 kW] 30 hp [22 kW] 4 kHz 60 Hz 130B2397 130B2386 45 A
40 hp [30 kW] 40 hp [30 kW] 3 kHz 60 Hz 130B2398 130B2387 75 A
50 hp [37 kW] 50 hp [37 kW] 3 kHz 60 Hz 130B2398 130B2387 75 A
60 hp [45 kW] 75 hp [55 kW] 3 kHz 60 Hz 130B2399 130B2388 110 A
75 hp [55 kW] 100 hp [75 kW] 3 kHz 60 Hz 130B2399 130B2388 110 A
100 hp [75 kW] 125 hp [90 kW] 3 kHz 60 Hz 130B2400 130B2389 182 A
125 hp [90 kW] 150 hp [110 kW] 3 kHz 60 Hz 130B2400 130B2389 182 A
150 hp [110 kW] 175 hp [132 kW] 3 kHz 60 Hz 130B2401 130B2390 280 A
175 hp [132 kW] 250 hp [160 kW] 3 kHz 60 Hz 130B2401 130B2390 280 A
250 hp [160 kW] 300 hp [200 kW] 3 kHz 60 Hz 130B2402 130B2391 400 A
300 hp [200 kW] 350 hp [250 kW] 3 kHz 60 Hz 130B2402 130B2391 400 A
350 hp [250 kW] 450 hp [315 kW] 3 kHz 60 Hz 130B2277 130B2275 500 A
450 hp [315 kW] 500 hp [355 kW] 2 kHz 60 Hz 130B2278 130B2276 750 A
500 hp [355 kW] 550 hp [400 kW] 2 kHz 60 Hz 130B2278 130B2276 750 A
550 hp [400 kW] 600 hp [450 kW] 2 kHz 60 Hz 130B2278 130B2276 750 A
600 hp [450 kW] 675 hp [500 kW] 2 kHz 60 Hz 130B2405 130B2393 910 A
675 hp [500 kW] 750 hp [560 kW] 2 kHz 60 Hz 130B2405 130B2393 910 A
750 hp [560 kW] 850 hp [630 kW] 2 kHz 60 Hz 130B2407 130B2394 1500 A
850 hp [630 kW] 950 hp [710 kW] 2 kHz 60 Hz 130B2407 130B2394 1500 A
950 hp [710 kW] 1075 hp [800 kW] 2 kHz 60 Hz 130B2407 130B2394 1500 A
1075 hp [800 kW] 1350 hp [1000 kW] 2 kHz 60 Hz 130B2407 130B2394 1500 A
1350 hp [1000 kW] 1475 hp [1100 kW] 2 kHz 60 Hz 130B2410 130B2395 2300 A
4 How to Order VLT
®
AQUA Drive Design Guide
4-14 MG.20.N5.22 - VLT
®
is a registered Danfoss trademark
4

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
