Danfoss vlt aqua Design Guide

4.2.4 Ordering Numbers: Sine Wave Filters, 525–600/690 V AC
Adjustable frequency drive size [kW] Part No. Danfoss
525–600 V 525–690 V
Current at 50 Hz
[A]
Minimum switch-
ing frequency
[kHz]
IP00 IP20
0.75 -
13 2 130B2321 130B2341
1.1 -
1.5 -
2.2 -
3.0 -
4.0 -
5.5 -
7.5 -
-11
28 2 130B2322 130B2342
11 15
15 18.5
18.5 22
22 30
45 2 130B2323 130B2343
30 37
37 45
76 2 130B2324 130B2344
45 55
55 75
115 2 130B2325 130B2345
75 90
90 110
165 2 130B2326 130B2346
110 132
150 160
260 2 130B2327 130B2347
180 200
220 250 303 2 130B2329 130B2348
260 315
430 1.5 130B2241 130B2270
300 400
375 500 530 1.5 130B2242 130B2271
450 560
660 1.5 130B2337 130B2381
480 630
560 710 765 1.5 130B2338 130B2382
670 800
940 1.5 130B2339 130B2383
-900
820 1000
1320 1.5 130B2340 130B2384
970 1200
Table 4.4: Line power supply 3x525–690 V
VLT
®
AQUA Drive Design Guide 4 How to Order
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 4-13
4

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
