Ordering Numbers: Brake Resistors
Line power 380–480 V
AC (T4-LP+MP+HP)
VLT AQUA Drive
Selected resistor
Standard IP 20
Flatpack IP65
for horizontal conveyors
Max. brake torque
with R
rec
Duty Cycle 10% Duty Cycle 40%
Size:
P
mo-
tor
R
min
R
br,no
m
R
rec
P
br avg
Order
no.
Period
R
rec
P
br avg
Order
no.
Period
R
rec
per
item
Duty cy-
cle
Order
no.
[kW] [Ω] [Ω] [Ω] [kW]
175U
xxxx
[s] [Ω] [kW]
175Ux
xxx
[s] [Ω/W] %
175Ux
xxx
%
PK37 0.37 620 1825 620 0.065 1840 120 620 0.26 1940 120 830/100 30 1000 110 (110)
PK55 0.55 620 1228 620 0.065 1840 120 620 0.26 1940 120 830/100 20 1000 110 (110)
PK75 0.75 485 896 620 0.065 1840 120 620 0.26 1940 120 830/100 20 1000 110 (110)
P1K1 1.1 329 608 620 0.065 1840 120 620 0.26 1940 120 630 - - 110 (110)
P1K5 1.5 240 443 425 0.095 1841 120 425 1.0 1941 120 430/100 10 1002 110 (110)
P1K5 1.5 240 443 425 0.095 1841 120 425 1.0 1941 120 430/200 20 0983 110 (110)
P2K2 2.2 161 299 310 0.25 1842 120 310 1.6 1942 120 320/200 14 0984 110 (110)
P3K0 3 117 217 210 0.285 1843 120 210 2.5 1943 120 215/200 10 0987 110 (110)
P4K0 4 86.9 161 150 0.43 1844 120 150 3.7 1944 120 150/200 14 0989 110 (110)
P4K0 4 86.9 161 150 0.43 1844 120 150 3.7 1944 120 300/200 7 2X098
5
110 (110)
P5K5 5.5 62.5 115 110 0.6 1845 120 110 4.7 1945 120 120/200 6 2X099
0
110 (110)
P7K5 7.5 45.3 83.7 80 0.85 1846 120 80 6.1 1946 120 82/240 5 2X009
0
110 (110)
P11K 11 34.9 56.4 40 2 1848 120 40 11 1948 120 - - - 110 (110)
P15K 15 25.3 40.9 40 2 1848 120 40 11 1948 120 - - - 110 (110)
P18K 18.5 20.3 32.8 30 2.8 1849 120 30 18 1949 120 - - - 110 (110)
P22K 22 16.9 27.3 25 3.5 1850 120 25 23 1950 120 - - - 110 (110)
P30K 30 13.2 20 20 4 1851 120 20 25 1951 120 - - - 110 (110)
P37K 37 10.6 16.1 15 4.8 1852 120 15 32 1952 120 - - - 110 (110)
P45K 45 8.7 13.2 12 5.5 1853 120 12 40 1953 120 - - - 110 (110)
P55K 55 6.6 10.8 10 15 2008 120 10 62 2007 120 - - - 110 (110)
P75K 75 6.6 8 7 13 0069 120 7 72 0068 120 - - - 110 (110)
P90K 90 3.6 7 5 18 1959 300 - - - - - - - 110 (110)
P110 110 3 5 5 18 1959 300 - - - - - - - 110 (110)
P132 132 2.5 5 4 22 1960 300 - - - - - - - 110 (110)
P160 160 2 4 3.8 22 1960 300 - - - - - - - 106 (110)
P200 200 1.6 2.9 2.6 32 1962 300 - - - - - - - 110 (110)
P250 250 1.2 2.4 2.1 39 1963 300 - - - - - - - 110 (110)
P315 315 1.2 1.9 2.1 39 1963 300 - - - - - - - 98 (110)
P355 355 1.2 1.7 - - - - - - - - - - - (110)
P400 400 1.2 1.5 - - - - - - - - - - - (110)
P450 450 1.2 1.3 - - - - - - - - - - - (110)
P500 500 1.2 1.3 - - - - - - - - - - - (100)
P560 560 1.2 1.3 - - - - - - - - - - - (89)
P630 630 1.2 1.3 - - - - - - - - - - - (79)
P710 710 1.2 1.3 - - - - - - - - - - - (70)
P800 800 1.2 1.3 - - - - - - - - - - - (62)
P1M0 1000 1.2 1.3 - - - - - - - - - - - (50)
VLT
®
AQUA Drive Design Guide 4 How to Order
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 4-17
