7.4.13 Process Words (PCD)
The block of process words is divided into two blocks of 16 bits, which always occur in the defined sequence.
PCD 1 PCD 2
Control message (master⇒slave control word) Reference value
Control message (slave ⇒master) Status word Present output frequency
