Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P45K
45
P55K
55
P75K
75
P90K
90
P110
110
P132
132
P160
160
P200
200
P250
250
P315
315
P400
400
P450
450
P500
500
P560
560
P630
630
P710
710
P800
800
P900
900
P1M0
1000
P1M2
1200
Typical Shaft Output [HP] at 575 V 50 60 75 100 125 150 200 250 300 350 400 450 500 600 650 750 950 1050 1150 1350
IP 00 D3 D3 D3 D3 D3 D3 D3 D4 D4 D4 D4 E2 E2 E2 E2 - - - - -
IP 21 / Nema 1 D1 D1 D1 D1 D1 D1 D1 D2 D2 D2 D2 E1 E1 E1 E1
F1/
F3
6)
F1/
F3
6)
F1/
F3
6)
F2/
F4
6)
F2/
F4
6)
IP 54 / Nema 12 D1 D1 D1 D1 D1 D1 D1 D2 D2 D2 D2 E1 E1 E1 E1
F1/
F3
6)
F1/
F3
6)
F1/
F3
6)
F1/
F3
6)
F1/
F3
6)
Output current
Continuous (3 x 550 V) [A] 56 76 90 113 137 162 201 253 303 360 418 470 523 596 630 763 889 988 1108 1317
Intermittent (3 x 550 V) [A] 62 84 99 124 151 178 221 278 333 396 460 517 575 656 693 839 978 1087 1219 1449
Continuous (3 x 690 V) [A] 54 73 86 108 131 155 192 242 290 344 400 450 500 570 630 730 850 945 1060 1260
Intermittent (3 x 690 V) [A] 59 80 95 119 144 171 211 266 319 378 440 495 550 627 693 803 935 1040 1166 1386
Continuous kVA (550 V AC) [kVA] 53 72 86 108 131 154 191 241 289 343 398 448 498 568 600 727 847 941 1056 1255
Continuous kVA (575 V AC) [kVA] 54 73 86 108 130 154 191 241 289 343 398 448 498 568 627 727 847 941 1056 1255
Continuous kVA (690 V AC) [kVA] 65 87 103 129 157 185 229 289 347 411 478 538 598 681 753 872 1016 1129 1267 1506
Max. cable size:
(line power) [mm
2
/ AWG]
2)
2x70
2x2/0
2x185
2x300 mcm
4x240
4x500 mcm
8x240
8x500 mcm
8x240
8x500 mcm
(Motor) [mm
2
/ AWG]
2)
2x70
2x2/0
2x185
2x300 mcm
4x240
4x500 mcm
8x150
8x300 mcm
12x150
12x300 mcm
(Brake) [mm
2
/ AWG]
2)
2x70
2x2/0
2x185
2x300 mcm
2x185
2x350 mcm
4x185
4x350 mcm
6x185
6x350 mcm
3.1.7 Line Power Supply 3 x 525–690 V AC
