Danfoss vlt aqua Design Guide

Normal overload 110% for 1 minute Adjustable frequency drive Typical Shaft Output [kW]
P45K
45
P55K
55
P75K
75
P90K
90
P110
110
P132
132
P160
160
P200
200
P250
250
P315
315
P400
400
P450
450
P500
500
P560
560
P630
630
P710
710
P800
800
P900
900
P1M0
1000
P1M2
1200
Typical Shaft Output [HP] at 575 V 50 60 75 100 125 150 200 250 300 350 400 450 500 600 650 750 950 1050 1150 1350
IP 00 D3 D3 D3 D3 D3 D3 D3 D4 D4 D4 D4 E2 E2 E2 E2 - - - - -
IP 21 / Nema 1 D1 D1 D1 D1 D1 D1 D1 D2 D2 D2 D2 E1 E1 E1 E1
F1/
F3
6)
F1/
F3
6)
F1/
F3
6)
F2/
F4
6)
F2/
F4
6)
IP 54 / Nema 12 D1 D1 D1 D1 D1 D1 D1 D2 D2 D2 D2 E1 E1 E1 E1
F1/
F3
6)
F1/
F3
6)
F1/
F3
6)
F1/
F3
6)
F1/
F3
6)
Max. input current
Continuous (3 x 550 V) [A] 60 77 89 110 130 158 198 245 299 355 408 453 504 574 607 743 866 962 1079 1282
Continuous (3 x 575 V) [A] 58 74 85 106 124 151 189 224 286 339 390 434 482 549 607 711 828 920 1032 1227
Continuous (3 x 690 V) [A] 58 77 87 109 128 155 197 240 296 352 400 434 482 549 607 711 828 920 1032 1227
Max. line power pre-fuses
1)
[A]
125 160 200 200 250 315 350 350 400 500 550 700 700 900 900 2000 2000 2000 2000 2000
Environment: Estimated power loss at 690 VAC at rated max. load [W]
4)
1458 1717 1913 2262 2662 3430 3612 4292 5156 5821 6149 6440 7249 8727 9673 11315
1290
3
14533
1637
5
19207
Estimated power loss at 575 VAC at rated max. load [W]
4)
1398 1645 1827 2157 2533 2963 3430 4051 4867 5493 5852 6132 6903 8343 9244 10771
1227
2
13835
1559
2
18281
Weight enclosure IP00 [kg] 82 82 82 82 82 82 91 112 123 138 151 221 221 236 277 - - - - -
Weight enclosure IP21 [kg] 6) 96 96 96 96 96 96 104 125 136 151 165 263 263 272 313 1004 1004 1004 1246 1246
Weight enclosure IP54 [kg] 6) 96 96 96 96 96 96 104 125 136 151 165 263 263 272 313 1004 1004 1004 1246 1246
Efficiency
3)
0.97 0.97 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98
1)
For type of fuse see section
Fuses
2)
American Wire Gauge
3)
Measured using 16 ft [5 m] shielded motor cables at rated load and rated frequency
4)
The typical power loss is at normal load conditions and expected to be within +/- 15% (tolerance relates to variety in voltage and cable conditions). Values are based on a typical motor efficiency (eff2/eff3 border
line). Lower efficiency motors will also add to the power loss in the adjustable frequency drive and vice versa. If the switching frequency is raised from nominal the power losses may rise significantly. LCP and typical control card power consumptions are included. Further options and customer load may add up to 30 [W] to the losses. (Though typically only 4 [W] extra for a fully loaded control card, or options for slot A or slot B, each). Although measurements are made with state of the art equipment, some measurement inaccuracy must be allowed for (+/- 5%).
6)
Adding the F-enclosure option cabinet (resulting in the F3 and F4 enclosure sizes) adds 650 lbs [295 kg] to the estimated weight.
VLT
®
AQUA Drive Design Guide 3 VLT AQUA Selection
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 3-13
3

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
