Danfoss vlt aqua Design Guide

FC 202, P37KT2
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
30 240 0.300 0.598 1.594
100 240 0.536 0.566 0.844
150 240 0.776 0.546 0.562
FC 202, P45KT2
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
30 240 0.300 0.598 1.594
100 240 0.536 0.566 0.844
150 240 0.776 0.546 0.562
FC 202, P1K5T4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
5 690 0.640 0.690 0.862
50 985 0.470 0.985
150 1045 0.760 1.045 0.947
FC 202, P4K0T4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
5 400 0.172 0.890 4.156
50 400 0.310 2.564
150 400 0.370 1.190 1.770
FC 202, P7K5T4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
5 500 0.04755 0.739 8.035
50 500 0.207 4.548
150 500 0.6742 1.030 2.828
FC 202, P11KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
15 480 0.192 1.300 5.416
100 480 0.612 1.300 1.699
150 480 0.512 1.290 2.015
FC 202, P15KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
36 480 0.396 1.210 2.444
100 480 0.844 1.230 1.165
150 480 0.696 1.160 1.333
FC 202, P18KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
36 480 0.396 1.210 2.444
100 480 0.844 1.230 1.165
150 480 0.696 1.160 1.333
3 VLT AQUA Selection VLT
®
AQUA Drive Design Guide
3-22 MG.20.N5.22 - VLT
®
is a registered Danfoss trademark
3

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
