Danfoss vlt aqua Design Guide

FC 202, P22KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
36 480 0.312 2.846
100 480 0.556 1.250 1.798
150 480 0.608 1.230 1.618
FC 202, P30KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
15 480 0.288 3.083
100 480 0.492 1.230 2.000
150 480 0.468 1.190 2.034
FC 202, P37KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
5 480 0.368 1.270 2.853
50 480 0.536 1.260 1.978
100 480 0.680 1.240 1.426
150 480 0.712 1.200 1.334
FC 202, P45KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
5 480 0.368 1.270 2.853
50 480 0.536 1.260 1.978
100 480 0.680 1.240 1.426
150 480 0.712 1.200 1.334
FC 202, P55KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
15 480 0.256 1.230 3.847
50 480 0.328 1.200 2.957
100 480 0.456 1.200 2.127
150 480 0.960 1.150 1.052
FC 202, P75KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
5 480 0.371 1.170 2.523
FC 202, P90KT4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
5 480 0.371 1.170 2.523
High Power Range:
FC 202, P110 - P250, T4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
30 400 0.34 1.040 2.447
VLT
®
AQUA Drive Design Guide 3 VLT AQUA Selection
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 3-23
3

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
