Danfoss vlt aqua Design Guide

FC 202, P315 - P1M0, T4
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
30 500 0.71 1.165 1.389
30 400 0.61 0.942 1.233
FC 202, P110 - P400, T7
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
30 690 0.38 1.513 3.304
30 575 0.23 1.313 2.750
30
690
1)
1.72 1.329 0.640
1) With Danfoss dU/dt filter.
FC 202, P450 - P1M2, T7
Cable length [m] AC line voltage [V] Rise time [μsec] Vpeak [kV] dU/dt [kV/μsec]
30 690 0.57 1.611 2.261
30 575 0.25 2.510
30
690
1)
1.13 1.629 1.150
1) With Danfoss dU/dt filter.
3 VLT AQUA Selection VLT
®
AQUA Drive Design Guide
3-24 MG.20.N5.22 - VLT
®
is a registered Danfoss trademark
3

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
