3 x analog inputs Operating range Resolution Accuracy Sampling Max load Impedance
Used as
temperature
sensor input
-58°–+302°F [-50°–
+150°C]
11 bits -58°F [-50°C]
±1 Kelvin
302°F [+150°C]
±2 Kelvin
3 Hz - -
Used as
voltage input
0–10 VDC 10 bits
0.2% of full
scale at cal.
temperature
2.4 Hz
+/- 20 V
continuously
Approximately
5 kΩ
When used for voltage, analog inputs are scalable by parameters for each input.
When used for temperature sensor, analog inputs scaling is preset to necessary signal level for specified temperature span.
When analog inputs are used for temperature sensors, it is possible to read out feedback value in both °C and °F.
When operating with temperature sensors, the maximum cable length to connect sensors is 262 ft [80 m] with non-shielded/non-twisted wires.
Analog outputs - terminal X42/7-12
Parameter group for readout and write: 18-3*. See also
Programming Guide
Parameter groups for set-up: 26-4*, 26-5* and 26-6*. See also
Programming Guide
3 x analog outputs Output signal level Resolution Linearity Max load
Volt 0–10 VDC 11 bits 1% of full scale 1 mA
Analog outputs are scalable by parameters for each output.
The function assigned is selectable via a parameter and has the same options as for analog outputs on the control card.
For a more detailed description of parameters, please refer to the
Programming Guide
.
Real-time clock (RTC) with back-up
The data format of RTC includes year, month, date, hour, minutes and weekday.
Accuracy of clock is better than ± 20 ppm at 77°F [25°C].
The built-in lithium back-up battery lasts on average for minimum 0 years, when adjustable frequency drive is operating at 104°F [40°C] ambient
temperature. If the battery back-up pack fails, the analog I/O option must be replaced.
VLT
®
AQUA Drive Design Guide 3 VLT AQUA Selection
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark
3-39
