5.2.11 Timed Actions, 23-0*
Use
Timed Actions
for actions needing to be performed on a daily or weekly basis, e.g., different references for working hours / non-working hours. Up
to 10 timed actions can be programmed in the adjustable frequency drive. The Timed Action number is selected from the list when entering parameter
group 23-0* from the Local Control Panel. par. 23-00
ON Time
– par. 23-04
Occurrence
then refer to the selected Timed Action number. Each timed
action is divided into an ON time and an OFF time, in which two different actions may be performed.
The actions programmed in Timed Actions are merged with corresponding actions from digital inputs, control word via bus and smart logic controller,
according to merge rules set up in 8-5*, Digital/Bus.
NOTE!
The clock (parameter group 0-7*) must be correctly programmed for timed actions to function correctly.
NOTE!
When mounting an Analog I/O MCB109 option card, a battery back-up of the date and time is included.
NOTE!
The PC-based configuration tool MCT 10 comprise a special guide for easy programming of timed actions.
23-00 ON Time
Array [10]
Range: Function:
Application
dependent*
[Application dependant]
23-01 ON Action
Arra [10]
Option: Function:
Select the action during ON Time. See par. 13-52
SL Controller Action
for descriptions of the options.
[0] * DISABLED
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
VLT AQUA High Power Instruction Manual
5 How to program the adjustable frequency
drive
MG.20.P3.22 - VLT
®
is a registered Danfoss trademark
5-45
