[16-66 ] Digital Output [bin]
[16-67 ] Freq. Input #29 [Hz]
[16-68 ] Freq. Input #33 [Hz]
[16-69 ] Pulse Output #27 [Hz]
[16-70 ] Pulse Output #29 [Hz]
[16-71 ] Relay Output [bin]
[16-75 ] Analog In X30/11
[16-76 ] Analog In X30/12
[16-77 ] Analog Out X30/8 [mA]
[16-84 ] Comm Option STW
[16-85 ] FC Port CTW 1
[16-90] Alarm Word
[16-91 ] Alarm Word 2
[16-92 ] Warning Word
[16-93 ] Warning Word 2
[16-94 ] Extended Status Word
[16-95 ] Extended Status Word
2
[16-96 ] Prev. Maintenance
Word
10-13 Warning Parameter
Range: Function:
0
*
[0 - 65535]
View a DeviceNet-specific Warning word. One bit is assigned to every warning. Please refer to the DeviceNet
Operating Instructions (MG.33.DX.YY) for further information.
Bit:
Meaning:
0 Bus not active
1 Explicit connection timeout
2 I/O connection
3 Retry limit reached
4 Actual is not updated
5CAN bus off
6 I/O send error
7 Initialization error
8 No bus supply
9Bus off
10 Error passive
11 Error warning
12 Duplicate MAC ID Error
13 RX queue overrun
14 TX queue overrun
15 CAN overrun
10-14 Net Reference
Read only from LCP.
Select the reference source in Instance 21/71 and 20/70.
[0]
*
Off Enables reference via analog/digital inputs.
[1] On Enables reference via the fieldbus.
10-15 Net Control
Read only from LCP.
3. Parameter Description VLT
®
HVAC Drive Programming Guide
110
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
3
