[1] AND Evaluates the expression [13-40/13-42] AND [13-44].
[2] OR Evaluates the expression [13-40/13-42] OR [13-44].
[3] AND NOT Evaluates the expression [13-40/13-42] AND NOT [13-44].
[4] OR NOT Evaluates the expression [13-40/13-42] OR NOT [13-44].
[5] NOT AND evaluates the expression NOT [13-40/13-42] AND [13-44].
[6] NOT OR Evaluates the expression NOT [13-40/13-42] OR [13-44].
[7] NOT AND NOT Evaluates the expression NOT [13-40/13-42] and evaluates AND NOT [13-44].
[8] NOT OR NOT Evaluates the expression NOT [13-40/13-42] OR NOT [13-44].
13-44 Logic Rule Boolean 3
Array [6]
Select the third boolean (TRUE or FALSE) input for the selected logic rule.
See Parameter 13-40 for further descriptions of choices and their functions.
3.13.6. 13-5* States
Parameters for programming the Smart Logic Controller.
13-51 SL Controller Event
Array [20]
Select the boolean input (TRUE or FALSE) to define the Smart Logic Controller event.
See Parameter 13-02 for further descriptions of choices and their functions.
13-52 SL Controller Action
Array [20]
Select the action corresponding to the SLC event. Actions are executed when the corresponding event (defined
in par. 13-51) is evaluated as true. The following actions are available for selection:
[0]
*
Disabled
[1] No action
[2] Select set-up 1 Changes the active set-up (par. 0-10) to ‘1’.
[3] Select set-up 2 Changes the active set-up (par. 0-10) to ‘2’.
[4] Select set-up 3 Changes the active set-up (par. 0-10) to ‘3’.
[5] Select set-up 4 Changes the active set-up (par. 0-10) to ‘4’. If the set-up is changed, it will merge with other set-up commands
coming from either the digital inputs or via a fieldbus.
[10] Select preset reference
0
Selects preset reference 0.
[11] Select preset reference
1
Selects preset reference 1.
[12] Select preset reference
2
Selects preset reference 2.
[13] Select preset reference
3
Selects preset reference 3.
[14] Select preset reference
4
Selects preset reference 4.
[15] Select preset reference
5
Selects preset reference 5.
[16] Select preset reference
6
Selects preset reference 6.
3. Parameter Description VLT
®
HVAC Drive Programming Guide
122 MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
