3.16.7. 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control words.
16-80 Fieldbus CTW 1
Range: Function:
0 * [0 - 65535]
View the two-byte Control word (CTW) received from the Bus-Master. Interpretation of the Control word depends
on the fieldbus option installed and the Control word profile selected in par. 8-10.
For more information please refer to the relevant fieldbus manual.
16-82 Fieldbus REF 1
Range: Function:
0 * [-200 - 200]
View the two-byte word sent with the control word form the Bus-Master to set the reference value.
For more information please refer to the relevant fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 * [0 - 65535]
View the extended fieldbus comm. option status word.
For more information please refer to the relevant fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 * [0 - 65535]
View the two-byte Control word (CTW) received from the Bus-Master. Interpretation of the control word depends
on the fieldbus option installed and the Control word profile selected in par. 8-10.
16-86 FC Port REF 1
Range: Function:
0 * [0 - 0]
View the two-byte Status word (STW) sent to the Bus-Master. Interpretation of the Status word depends on the
fieldbus option installed and the Control word profile selected in par. 8-10.
3.16.8. 16-9* Diagnosis Read-Out
Parameters displaying alarm, warning and extended status words.
16-90 Alarm Word
Range: Function:
0 * [0 - FFFFFFFF]
View the alarm word sent via the serial communication port in hex code.
16-91 Alarm Word 2
Range: Function:
0 * [0 - FFFFFFFF]
View the alarm word 2 sent via the serial communication port in hex code.
16-92 Warning Word
Range: Function:
0 * [0 - FFFFFFFF]
View the warning word sent via the serial communication port in hex code.
16-93 Warning Word 2
Range: Function:
0 * [0 - FFFFFFFF]
View the warning word 2 sent via the serial communication port in hex code.
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark 147
