21-39 Ext. 2 Output [%]
Option: Function:
See par. 21-19, Ext. 1 Output [%] , for details.
3.19.6. 21-4* Closed Loop 2 PID
Configure the Closed Loop 2 PID Controller.
21-40 Ext. 2 Normal/Inverse Control
Option: Function:
See par. 21-20, Ext. 1 Normal/Inverse Control , for details.
21-41 Ext. 2 Proportional Gain
Option: Function:
See par. 21-21, Ext. 1 Proportional Gain , for details.
21-42 Ext. 2 Integral Time
Option: Function:
See par. 21-22, Ext. 1 Integral Time , for details.
21-43 Ext. 2 Differentiation Time
Option: Function:
See par. 21-23, Ext. 1 Differentiation Time , for details.
21-44 Ext. 2 Diff. Gain Limit
Option: Function:
See par. 21-24, Ext. 1 Diff. Gain Limit , for details.
3.19.7. 21-5* Closed Loop 3 Ref/Fb
Configure Extended Closed Loop 3 Controller reference and feedback.
21-50 Ext. 3 Ref/Feedback Unit
Option: Function:
See par. 21-10, Ext. 1 Ref/Feedback Unit , for details.
21-51 Ext. 3 Minimum Reference
Option: Function:
See par. 21-11, Ext. 1 Minimum Reference , for details.
21-52 Ext. 3 Maximum Reference
Option: Function:
See par. 21-12, Ext. 1 Maximum Reference , for details.
21-53 Ext. 3 Reference Source
Option: Function:
See par. 21-13, Ext. 1 Reference Source , for details.
21-54 Ext. 3 Feedback Source
Option: Function:
See par. 21-14, Ext. 1 Feedback Source , for details.
21-55 Ext. 3 Setpoint
Option: Function:
See par. 21-15, Ext. 1 Setpoint , for details.
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark 171
3
