[109] Max Out Freq
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[139] Bus ctrl.
[141] Bus ctrl timeout
26-41 Terminal X42/7 Output Min. Scale
Range: Function:
0%
*
[0.00 - 200%]
Scale the minimum output of the selected analog signal at terminal X42/7, as a percentage of the maximum
signal level. E.g. if a 0 V (or 0 Hz) is desired at 25% of the maximum output value. Then programme 25%. Scaling
values up to 100% can never be higher than the corresponding setting in par 26-42.
See principle graph for parameter 6-51.
26-42 Terminal X42/7 Output Max. Scale
Range: Function:
100%
*
[0 - 200%]
Scale the maximum output of the selected analog signal at terminal X42/7. Set the value to the maximum value
of the voltage signal output. Scale the output to give a voltage lower than 10V at full scale; or 10V at an output
below 100% of the maximum signal value. If 10V is the desired output current at a value between 0-100% of
the full-scale output, programme the percentage value in the parameter, i.e. 50% = 10V. If a voltage between
0 and 10V is desired at maximum output, calculate the percentage as follows:
(
10
V
desired maximum voltage
)
x
100 %
i.e.
5
V
:
10
V
5
V
× 100 % = 200 %
See principle graph for parameter 6-52.
26-43 Terminal X42/7 Output Bus Control
Range: Function:
0%
*
[0 - 100%]
Holds the level of terminal X42/7 if controlled by bus.
26-44 Terminal X42/7 Output Timeout Preset
Range: Function:
0.00 %
*
[0.00 - 100%]
Holds the preset level of terminal X42/7.
In case of a bus timeout and a timeout function is selected in par 26-50 the output will preset to this level.
26-50 Terminal X42/9 Output
Option: Function:
Set the function of terminal X42/9.
[0]
*
No operation
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to lim.
[105] Torque rel to rated
[106] Power
3. Parameter Description VLT
®
HVAC Drive Programming Guide
228
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
3
