26-30 Terminal X42/5 Low Voltage
Range: Function:
0.07 V
*
[0.00 - par. 26-31]
Enter the low voltage value. This analog input scaling value should correspond to the low reference/feedback
value set in par 26-34.
26-31 Terminal X42/5 High Voltage
Range: Function:
10.0 V
*
[Par. 26-30 - 10.0 V]
Enter the high voltage value. This analog input scaling value should correspond to the high reference/feedback
value set in par 26-35.
26-34 Terminal X42/5 Low Ref./feedb. Value
Range: Function:
0.000 Unit
*
[-100000.000 - Par.
26-35]
Enter the analog input scaling value that corresponds to the low voltage value set in par 26-30.
26-35 Terminal X42/5 High Ref./feedb. Value
Range: Function:
100.000 Unit
*
[Par. 26-34 -
1000000.000]
Enter the analog input scaling value that corresponds to the high voltage value set in par 26-21.
26-36 Terminal X42/5 Filter Time Constant
Range: Function:
0.001 s
*
[0.001 - 10.000 s]
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing noise in terminal
X42/5. A high time constant value improves dampening but also increases the time delay through the filter. This
parameter cannot be adjusted while the motor is running.
26-37 Terminal X42/5 Live Zero
Option: Function:
This parameter makes it possible to enable the Live Zero monitoring. E.g. where the analog input is a part of
the frequency converter control, rather than being used as part of a decentral I/O system, such as a Building
Management System.
[0] Disabled
[1] Enabled
26-40 Terminal X42/7 Output
Option: Function:
Set the function of terminal X42/7 as an analog voltage output.
[0]
*
No operation
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to lim.
[105] Torque rel to rated
[106] Power
[107] Speed
[108] Torque
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
227
3
