Danfoss VLT FC 100 Series Programming Guide

Par. No. # Parameter description Default value
(SR = Size related)
4-set-up FC 302
only
Change during op-
eration
Conver-
sion index
Type
4-1* Motor Limits 4-10 Motor Speed Direction [2] Both directions All set-ups FALSE - Uint8 4-11 Motor Speed Low Limit [RPM] SR All set-ups TRUE 67 Uint16
4-12 Motor Speed Low Limit [Hz] SR All set-ups TRUE -1 Uint16
4-13 Motor Speed High Limit [RPM] SR All set-ups TRUE 67 Uint16
4-14 Motor Speed High Limit [Hz] SR All set-ups TRUE -1 Uint16
4-16 Torque Limit Motor Mode 110.0 % All set-ups TRUE -1 Uint16
4-17 Torque Limit Generator Mode 100.0 % All set-ups TRUE -1 Uint16
4-18 Current Limit SR All set-ups TRUE -1 Uint32
4-19
Max Output Frequency SR All set-ups FALSE -1 Uint16
4-5* Adj. Warnings 4-50 Warning Current Low 0.00 A All set-ups TRUE -2 Uint32 4-51 Warning Current High ImaxVLT (P1637) All set-ups TRUE -2 Uint32
4-52 Warning Speed Low 0 RPM All set-ups TRUE 67 Uint16
4-53 Warning Speed High outputSpeedHighLimit (P413) All set-ups TRUE 67 Uint16
4-54 Warning Reference Low -999999.999 N/A All set-ups TRUE -3 Int32
4-55 Warning Reference High 999999.999 N/A All set-ups TRUE -3 Int32
4-56 Warning Feedback Low -999999.999 ProcessCtrlUnit All set-ups TRUE -3 Int32
4-57 Warning Feedback High 999999.999 ProcessCtrlUnit All set-ups TRUE -3 Int32
4-58
Missing Motor Phase Function [1] On All set-ups TRUE - Uint8
4-6* Speed Bypass 4-60 Bypass Speed From [RPM] SR All set-ups TRUE 67 Uint16 4-61 Bypass Speed From [Hz] SR All set-ups TRUE -1 Uint16
4-62 Bypass Speed To [RPM] SR All set-ups TRUE 67 Uint16
4-63 Bypass Speed To [Hz] SR All set-ups TRUE -1 Uint16
4-64 Semi-Auto Bypass Set-up [0] Off All set-ups FALSE - Uint8
5.1.6. 4-** Limits / Warnings
VLT
®
HVAC Drive Programming Guide 5. Parameter Lists
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark 247
5
