Danfoss VLT FC 100 Series Programming Guide

Par. No. # Parameter description Default value
(SR = Size related)
4-set-up FC 302
only
Change during op-
eration
Conver-
sion index
Type
6-0* Analog I/O Mode 6-00 Live Zero Timeout Time 10 s All set-ups TRUE 0 Uint8 6-01 Live Zero Timeout Function [0] Off All set-ups TRUE - Uint8
6-02
Fire Mode Live Zero Timeout Function [0] Off All set-ups TRUE - Uint8
6-1* Analog Input 53 6-10 Terminal 53 Low Voltage 0.07 V All set-ups TRUE -2 Int16 6-11 Terminal 53 High Voltage 10.00 V All set-ups TRUE -2 Int16
6-12 Terminal 53 Low Current 4.00 mA All set-ups TRUE -5 Int16
6-13 Terminal 53 High Current 20.00 mA All set-ups TRUE -5 Int16
6-14 Terminal 53 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
6-15 Terminal 53 High Ref./Feedb. Value SR All set-ups TRUE -3 Int32
6-16 Terminal 53 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
6-17 Terminal 53 Live Zero [1] Enabled All set-ups TRUE - Uint8 6-2* Analog Input 54 6-20 Terminal 54 Low Voltage 0.07 V All set-ups TRUE -2 Int16 6-21 Terminal 54 High Voltage 10.00 V All set-ups TRUE -2 Int16 6-22 Terminal 54 Low Current 4.00 mA All set-ups TRUE -5 Int16
6-23 Terminal 54 High Current 20.00 mA All set-ups TRUE -5 Int16
6-24 Terminal 54 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
6-25 Terminal 54 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
6-26 Terminal 54 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
6-27
Terminal 54 Live Zero [1] Enabled All set-ups TRUE - Uint8
6-3* Analog Input X30/11 6-30 Terminal X30/11 Low Voltage 0.07 V All set-ups TRUE -2 Int16 6-31 Terminal X30/11 High Voltage 10.00 V All set-ups TRUE -2 Int16
6-34 Term. X30/11 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
6-35 Term. X30/11 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
6-36 Term. X30/11 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
6-37 Term. X30/11 Live Zero [1] Enabled All set-ups TRUE - Uint8 6-4* Analog Input X30/12 6-40 Terminal X30/12 Low Voltage 0.07 V All set-ups TRUE -2 Int16 6-41 Terminal X30/12 High Voltage 10.00 V All set-ups TRUE -2 Int16 6-44 Term. X30/12 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
6-45 Term. X30/12 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
6-46 Term. X30/12 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
6-47 Term. X30/12 Live Zero [1] Enabled All set-ups TRUE - Uint8
5.1.8. 6-** Analog In / Out
5. Parameter Lists VLT
®
HVAC Drive Programming Guide
250 MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
5
