Danfoss VLT FC 100 Series Programming Guide

Par. No. # Parameter description Default value
(SR = Size related)
4-set-up FC 302
only
Change during op-
eration
Conver-
sion index
Type
14-0* Inverter Switching 14-00 Switching Pattern [0] 60 AVM All set-ups TRUE - Uint8 14-01 Switching Frequency null All set-ups TRUE - Uint8
14-03 Overmodulation [1] On All set-ups FALSE - Uint8
14-04 PWM Random [0] Off All set-ups TRUE - Uint8 14-1* Mains On/Off 14-10 Mains Failure [0] No function All set-ups FALSE - Uint8 14-11 Mains Voltage at Mains Fault SR All set-ups TRUE 0 Uint16 14-12 Function at Mains Imbalance [0] Trip All set-ups TRUE - Uint8 14-2* Reset Functions 14-20 Reset Mode null All set-ups TRUE - Uint8 14-21 Automatic Restart Time 10 s All set-ups TRUE 0 Uint16 14-22 Operation Mode [0] Normal operation All set-ups TRUE - Uint8
14-23 Typecode Setting null 2 set-ups FALSE - Uint8
14-25 Trip Delay at Torque Limit 60 s All set-ups TRUE 0 Uint8
14-26 Trip Delay at Inverter Fault SR All set-ups TRUE 0 Uint8
14-28 Production Settings [0] No action All set-ups TRUE - Uint8
14-29
Service Code 0 N/A All set-ups TRUE 0 Int32
14-3* Current Limit Ctrl. 14-30 Current Lim Ctrl, Proportional Gain 100 % All set-ups FALSE 0 Uint16 14-31 Current Lim Ctrl, Integration Time 0.020 s All set-ups FALSE -3 Uint16 14-4* Energy Optimising 14-40 VT Level 66 % All set-ups FALSE 0 Uint8 14-41 AEO Minimum Magnetisation SR All set-ups TRUE 0 Uint8 14-42 Minimum AEO Frequency 10 Hz All set-ups TRUE 0 Uint8
14-43
Motor Cosphi SR All set-ups TRUE -2 Uint16
14-5* Environment 14-50 RFI Filter [1] On 1 set-up FALSE - Uint8 14-52 Fan Control [0] Auto All set-ups TRUE - Uint8
14-53 Fan Monitor [1] Warning All set-ups TRUE - Uint8
14-6* Auto Derate 14-60 Function at Over Temperature [0] Trip All set-ups TRUE - Uint8 14-61 Function at Inverter Overload [0] Trip All set-ups TRUE - Uint8
14-62 Inv. Overload Derate Current 95 % All set-ups TRUE 0 Uint16
5.1.14. 14-** Special Functions
VLT
®
HVAC Drive Programming Guide 5. Parameter Lists
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark 257
5
