Danfoss VLT FC 100 Series Programming Guide

NB!
Changing the value of these parameters affects the setting of other parameters.
1-20 Motor Power [kW]
Range: Function:
Size related * [0.09 - 1200 kW]
Enter the nominal motor power in kW according to the motor nameplate data. The default value corresponds to
the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running. Depending on the choices made in par.
0-03
Regional Settings
, either par. 1-20 or par. 1-21 Motor Power is made invisible.
1-21 Motor Power [HP]
Range: Function:
Size related * [0.09 - 900 HP]
Enter the nominal motor power in HP according to the motor nameplate data. The default value corresponds to
the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Depending on the choices made in par. 0-03
Regional Settings , either par. 1-20 orpar. 1-21 Motor Power is
made invisible.
1-22 Motor Voltage
Range: Function:
Size related * [10 - 1000 V]
Enter the nominal motor voltage according to the motor nameplate data. The default value corresponds to the
nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running.
1-23 Motor Frequency
Range: Function:
Size related * [20 - 1000 Hz]
Select the motor frequency value from the motor nameplate data. For 87 Hz operation with 230/400 V motors,
set the nameplate data for 230 V/50 Hz. Adapt par. 4-13
Motor Speed High Limit [RPM) and par. 3-03 Maximum
Reference
to the 87 Hz application.
This parameter cannot be adjusted while the motor is running.
1-24 Motor Current
Range: Function:
Size related * [0.1 - 10000 A]
Enter the nominal motor current value from the motor nameplate data. This data is used for calculating motor
torque, motor thermal protection etc.
This parameter cannot be adjusted while the motor is running.
1-25 Motor Nominal Speed
Range: Function:
Size related * [100 - 60,000 RPM]
Enter the nominal motor speed value from the motor nameplate data. This data is used for calculating automatic
motor compensations.
This parameter cannot be adjusted while the motor is running.
3. Parameter Description VLT
®
HVAC Drive Programming Guide
40 MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
