[80] SL Digital Output A
[81] SL Digital Output B
[82] SL Digital Output C
[83] SL Digital Output D
[84] SL Digital Output E
[85] SL Digital Output F
[160] No Alarm
[161] Running Reverse
[165] Local Ref. Active
[166] Remote Ref. Active
[167] Start Cmd. Active
[168] Drive in Hand Mode
[169] Drive in Auto Mode
[180] Clock Fault
[181] Prev. Maintenance
[190] No-Flow
[191] Dry Pump
[192] End of Curve
[193] Sleep Mode
[194] Broken Belt
[195] Bypass Valve Control
[196] Fire Mode
[197] Fire Mode was Active
[198] Drive Bypass
[211] Cascade Pump1
[212] Cascade Pump2
[213] Cascade Pump3
[220] Fire Mode Active
[221] Fire Mode Coast
[222] Fire Mode Was Active
[223] Alarm, Trip Locked
[224] Bypass Mode Active
5-41 On Delay, Relay
Option: Function:
Enter the delay of the relay cut-in time. Select one of available mechanical relays and MCO 105 in an array
function. See par. 5-40. Relay 3-6 are included in MCB 112 (ATEX).
Array [8] (Relay 1 [0], Relay 2 [1], Relay 3 [2], Relay 4 [3], Relay 5 [4], Relay 6 [5], Relay 7 [6], Relay 8 [7], Relay 9 [8])
0.01 s
*
[0.01 - 600.00 s ]
3. Parameter Description VLT
®
HVAC Drive Programming Guide
74
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
