Danfoss vlt FC 102 Installation Guide

5.4 Fuses
5.4.1 Fuse Selection
To protect the drive system in case 1 or more internal
components break down within a drive module, use fuses
and/or circuit breakers at the mains supply side.
5.4.1.1 Branch Circuit Protection
To protect the installation against electrical and re
hazards, protect all branch circuits in an installation against
short circuit and overcurrent according to national and
international regulations.
5.4.1.2 Short-circuit Protection
Danfoss recommends the fuses listed in
chapter 5.4.1.3 Recommended Fuses for CE Compliance and
chapter 5.4.1.4 Recommended Fuses for UL Compliance to
achieve CE or UL Compliance in the protection of service
personnel and property against the consequences of
component breakdown in the drive modules.
5.4.1.3 Recommended Fuses for CE
Compliance
Number of drive
modules
FC 302 FC 102/
FC 202
Recommended fuse
(maximum)
2 N450 N500 aR-1600
4 N500 N560 aR-2000
4 N560 N630 aR-2000
4 N630 N710 aR-2500
4 N710 N800 aR-2500
4 N800 N1M0 aR-2500
Table 5.1 6-Pulse Drive Systems (380–500 V AC)
Number of drive
modules
FC 302 FC 102/
FC 202
Recommended fuse
(maximum)
2 N250 N315 aR-630
2 N315 N355 aR-630
2 N355 N400 aR-630
2 N400 N450 aR-800
2 N450 N500 aR-800
4 N500 N560 aR-900
4 N560 N630 aR-900
4 N630 N710 aR-1600
4 N710 N800 aR-1600
4 N800 N1M0 aR-1600
Table 5.2 12-Pulse Drive Systems (380–500 V AC)
Number of drive
modules
FC 302 FC 102/
FC 202
Recommended fuse
(maximum)
4 N630 N710 aR-1600
4 N710 N800 aR-2000
4 N800 N900 aR-2500
4 N900 N1M0 aR-2500
4 N1M0 N1M2 aR-2500
Table 5.3 6-Pulse Drive Systems (525–690 V AC)
Number of drive
modules
FC 302 FC 102/
FC 202
Recommended fuse
(maximum)
2 N250 N315 aR-550
2 N315 N355 aR-630
2 N355 N400 aR-630
2 N400 N500 aR-630
2 N500 N560 aR-630
2 N560 N630 aR-900
4 N630 N710 aR-900
4 N710 N800 aR-900
4 N800 N900 aR-900
4 N900 N1M0 aR-1600
4 N1M0 N1M2 aR-1600
Table 5.4 12-Pulse Drive Systems (525–690 V AC)
5.4.1.4 Recommended Fuses for UL
Compliance
•
The drive modules are supplied with built-in AC
fuses. The modules have been qualied for
100 kA short-circuit current rating (SCCR) for the
standard busbar congurations at all voltages
(380–690 V AC).
•
If no power options or extra busbars are
connected externally, the drive system is qualied
for 100 kA SCCR with any Class L or Class T UL-
listed fuses connected at the input terminals of
the drive modules.
•
Do not exceed the listed fuse rating in Table 5.6
to Table 5.7 with the current rating of the Class L
or Class T fuses.
Number of drive
modules
FC 302 FC 102/
FC 202
Recommended fuse
(maximum)
2 N450 N500 1600 A
4 N500 N560 2000 A
4 N560 N630 2000 A
4 N630 N710 2500 A
4 N710 N800 2500 A
4 N800 N1M0 2500 A
Table 5.5 6-Pulse Drive Systems (380–500 V AC)
Electrical Installation
VLT
®
Parallel Drive Modules
22 Danfoss A/S © 08/2017 All rights reserved. MG37K302
