Power range N560 N630 N710 N800 N1M0
Drive modules 4 4 4 4 4
Rectier conguration 6-pulse/12-pulse
High/normal load HO NO HO NO HO NO HO NO HO NO
Output current [A]
Continuous (at 400 V) 880 990 990 1120 1120 1260 1260 1460 1460 1720
Intermittent (60 s overload) at 400 V 1320 1089 1485 1232 1680 1386 1890 1606 2190 1892
Continuous (at 460/500 V) 780 890 890 1050 1050 1160 1160 1380 1380 1530
Intermittent (60 s overload) at
460/500 V
1170 979 1335 1155 1575 1276 1740 1518 2070 1683
Input current [A]
Continuous (at 400 V) 857 964 964 1090 1090 1227 1127 1422 1422 1675
Continuous (at 460 V) 759 867 867 1022 1022 1129 1129 1344 1344 1490
Power losses [W]
Drive modules at 400 V 7713 8810 8918 10199 10181 11632 11390 13253 13479 16463
Drive modules at 460 V 6641 7628 7855 9324 9316 10375 12391 12391 12376 13958
AC bus bars at 400 V 655 665 665 680 680 695 695 722 722 762
AC bus bars at 460 V 647 656 656 671 671 683 683 710 710 732
DC bus bars during regeneration 218 218 232 232 250 250 276 276 318 318
Maximum cable size [mm
2
(mcm)]
Mains 4x185 (350) 8x125 (250)
Motor 4x185 (350) 8x125 (250)
Brake 8x70 (2/0) 8x95 (3/0)
Regeneration terminals
1)
6x125 (250)
8x125 (250) 8x150 (300) 10x150 (300)
Maximum external mains fuses
6-pulse conguration 600 V, 1600 A 600 V, 2000 A 600 V, 2500 A
12-pulse conguration 600 V, 900 A 600 V, 1500 A
Table 7.6 FC 202, 380–480 V AC Mains Supply (4-Drive System)
1) If Danfoss bus bar kit is used.
