7.1.3
VLT
®
AutomationDrive FC 302
Power range N250 N315 N355 N400 N450
Drive modules 2 2 2 2 2
Rectier conguration 12-pulse 6-pulse/12-pulse
High/normal load HO NO HO NO HO NO HO NO HO NO
Output current [A]
Continuous (at 380–440 V) 480 588 600 658 658 745 695 800 810 880
Intermittent (60 s overload) at 400 V 720 647 900 724 987 820 1043 880 1215 968
Continuous (at 460/500 V) 443 535 540 590 590 678 678 730 730 780
Intermittent (60 s overload) at
460/500 V
665 588 810 649 885 746 1017 803 1095 858
Input current [A]
Continuous (at 400 V) 463 567 590 647 647 733 684 787 779 857
Continuous (at 460/500 V) 427 516 531 580 580 667 667 718 711 759
Power losses [W]
Drive modules at 400 V 4505 5825 5502 6110 6110 7069 6375 7538 7526 8468
Drive modules at 460 V 4063 4998 5384 5964 5721 6175 6070 6609 6604 7140
AC bus bars at 400 V 545 550 551 555 555 561 557 565 566 575
AC bus bars at 460 V 543 548 548 551 556 556 556 560 560 563
Maximum cable size [mm
2
(mcm)]
Mains 4x120 (250) 4x150 (300)
Motor 4x120 (250) 4x150 (300)
Brake 4x70 (2/0) 4x95 (3/0)
Regeneration terminals
1)
4x120 (250) 4x150 (300) 6x120 (250)
Maximum external mains fuses
6-pulse conguration – – – – 600 V, 1600 A
12-pulse conguration 600 V, 700 A 600 V, 900 A
Table 7.10 FC 302, 380–500 V AC Mains Supply (2-Drive System)
1) If Danfoss bus bar kit is used.
Specications
VLT
®
Parallel Drive Modules
54 Danfoss A/S © 08/2017 All rights reserved. MG37K302
77

Danfoss vlt FC 102 Specifications

General

Category	DC Drives
Model	Danfoss VLT FC 102
Output voltage range	0 to rated motor voltage
Power range	0.37 kW to 200 kW
Communication interfaces	RS-485
Protection features	Overvoltage, undervoltage, overcurrent, short circuit, earth fault, overtemperature, motor thermal protection
Cooling method	Air-cooled
Enclosure rating	IP20, IP21, IP55 (depending on model)
Approvals	CE, UL, cUL
